Action: Keypad UP
i
Figure 3.9: PWE with RTD option initial Process Information Screen
Pressing UP button, pages through the PI screens in the forward direction.
Pressing DN button, pages through the PI screens in the reverse direction. When
the last PI screen is reached, the firmware "wraps around" and scrolls to the initial
PI screen once again.
3.1.2 PWE without RTD option Process
Information Screens
Pressing UP and DN buttons from initial PI screen will switch display as following:
[Initial PI screen]
Action: Keypad UP
i
Figure 3.10: PWE without RTD option PI Screen with Main and Pilot Totalizer
Action: Keypad UP
i
Figure 3.11: PWE without RTD option initial PI Screen with Main and Pilot
Totalizer
MT: 60639.38 Gal
PT: 65.81 Gal
5.001 Gl/min AD
20.1 C TA: D
5.001 Gl/min AD
PT: 65.81 Gal
