iDynamo MagneSafe V5 Communication Manual
22
Cmd Num Data Len Prp ID Prp Value
01 04 1F 31 32 33
Example Set Post-Card String property Response (Hex):
Result Code Data Len Data
00 00
Example Get Post-Card String property Request (Hex):
Cmd Num Data Len Prp ID
00 01 1F
Example Get Post-Card String property Response (Hex):
Result Code Data Len Prp Value
00 03 31 32 33
Pre-Track String Property
Property ID: 0x20
Property Type: String
Length: 0-7 bytes
Get Property: Yes
Set Property: Yes
Default Value: No string with a length of zero.
Description: This string is sent prior to the data for each track. The string can be 0 – 7
bytes long. If the value is 0 no character is sent.
This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled for these changes to take effect.
Example Set Pre-Track String property Request (Hex):
Cmd Num Data Len Prp ID Prp Value
01 04 20 31 32 33
Example Set Pre-Track String property Response (Hex):
Result Code Data Len Data
00 00
Example Get Pre-Track String property Request (Hex):
Cmd Num Data Len Prp ID
00 01 20
Example Get Pre-Track String property Response (Hex):
Result Code Data Len Prp Value
00 03 31 32 33
