Section 2. Communications
13
Property ID
Property ID is a one-byte field that contains a hex value that identifies the property. The
following table lists all the current property ID values:
Property
ID
P-
Value
Property Description
0x00 Software ID The reader’s software identifier
0x03 Device Serial Num The reader’s serial number
0x04 MagneSafe Version Number Version number of MagneSafe feature set
0x05 Track ID Enable Track enable / ID enable
0x07 ISO Track Mask Specifies Masking factors for ISO cards
0x08 AAMVA Track Mask Specifies Masking factors for AAMVA cards
0x10 Interface Type Type of interface
0x14 Track Data Send Flags Track data send flags
0x15 MP Flags Enables sending of MagnePrint data
0x19 CRC Flag Enables/disables sending CRC
0x1B Decode Enable Enables decoding for certain formats
0x1C SS JIS TYPE 2 Start sentinel character for JIS type 2
0x1D ES JIS TYPE 2 End Sentinel Character for JIS type 2
0x1E P30 Pre-Card String Pre card string
0x1F P31 Post-Card String Post card string
0x20 P32 Pre-Track String Pre track string
0x21 P33 Post-Track String Post track string
0x22 P34 Termination String Terminating string
0x23 P35 FS Field Separator for additional data
0x24 P36 SS Track 1 ISO ABA Start sentinel char for track 1 – ISO/ABA
0x25 P37 SS Track 2 ISO ABA Start sentinel char for track 2 – ISO/ABA
0x26 P38 SS Track 3 ISO ABA Start sentinel char for track 3 – ISO/ABA
0x27 P39 SS Track 3 AAMVA Start sentinel char for track 3 – AAMVA
0x28 P40 SS Track 2 7BITS Start sentinel char for track 2 – 7 bit data
0x29 P41 SS Track 3 7BITS Start sentinel char for track 3 – 7 bit data
0x2B P43 ES
End sentinel char for all tracks/formats except JIS
type 2
0x2C Format Code
Defines the Format Code to be sent with the
message
0x2D P45 ES Track 1 End sentinel char for track 1
0x2E P46 ES Track 2 End sentinel char for track 2 except JIS type 2
0x2F P47 ES Track 3 End sentinel char for track 3
0x30 Send Encryption Counter Enables/disables sending Encryption Counter
0x31 Mask Other Cards
Enables/disables masking of cards that don’t
meet the ISO Financial or the AAMVA formats
0x34 Send clear AAMVA card data
Enables/disables sending of clear AAMVA card
data
0x50 Bundle Seed ID String Shows Bundle Seed ID
0x51 SDK Protocol Token String Shows SDK Protocol String
The Property Value is a multiple-byte field that contains the value of the property. The number
of bytes in this field depends on the type of property and the length of the property. The
following table lists all of the property types and describes them.
