iDynamo MagneSafe V5 Communication Manual
18
Track Data Send Flags Property
Property ID:
0x14
Property Type:
Byte
Length:
1 byte
Get Property:
Yes
Set Property:
Yes
Default Value:
0x63
Description:
This property is defined as follows:
ICL
SS
ES
0
0
LC
Er
Er
ICL
0 – Changing the state of the caps lock key will not affect the case of the data
1 – Changing the state of the caps lock key will affect the case of the data
SS
0 – Don’t send Start Sentinel for each track
1 – Send Start Sentinel for each track
ES
0 – Don’t send End Sentinel for each track
1 – Send End Sentinel for each track
LC
0 – Send card data as upper case
1 – Send card data as lower case
Er
00 – Don’t send any card data if error – NOT CURRENTLY IMPLEMENTED
01 – Don’t send track data if error
11 – Send ‘E’ for each track error
This property is stored in non-volatile memory, so it will persist when the unit is
power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled for these changes to take effect.
MP Flags Property
Property ID:
0x15
Property Type:
Byte
Length:
1 byte
Get Property:
Yes
Set Property:
Yes
Default Value:
0x00
Description:
This property is defined as follows:
0
0
0
0
0
0
0
S
S
0 – MagnePrint Data will NOT be sent
1 – MagnePrint Data will be sent.
This property is used to designate whether or not the MagnePrint data is sent as part of a
card swipe message. Setting S to 1 causes the MagnePrint Status and Unencrypted
MagnePrint Data to be sent with each swipe. Setting S to 0 causes these fields to be
omitted from the data. When these fields are omitted, the Programmable Field Separator
that precedes each of these fields will also be omitted.
