1 - Introduction
iDynamo| MagneSafe Secure Card Reader Authenticator | Technical Reference Manual
Page 8

Which iOS device will iDynamo be attached to? This informs which iDynamo model you need.

What electromechanical interface will you use to attach and interface iDynamo with the iOS device?
This informs which iDynamo model and which adapters you need.

What application(s) will you use to test the device? What application(s) will you use to process
transactions? This informs what additional software infrastructure you will need to put in place.
1.3.1 Choose an iDynamo Model
Use Table 2 to determine which model of iDynamo is appropriate for your solution:
Table 2 - iDynamo Model Selection
Model Part # Tracks Interface Compatible With
iDynamo 21073084 1,2,3 30-pin iPhone 3G/3GS/4/4S, iPad 2/3, iPod Touch
iDynamo 5 21073131 1,2,3 Lightning iPhone 5, iPad Mini, iPad with Retina Display,
and iPod Touch 5 th Generation
1.3.2 Choose Adapters / Accessories
Use Table 3 to determine which adapters and / or accessories are appropriate for your solution. To help
with selection, the adapters are shown graphically in Appendix B.
Table 3 - Adapters and Accessories
Part Number Description Optional/Included
93600175
2’ 30-pin extension cable for use with iPad
Optional
21041054 iPad 2/3 adapter sleeve Included with iDynamo
21041051 iPad adapter sleeve Included with iDynamo
21041087 iPad Mini adapter sleeve Included with iDynamo 5
21041086 iPad with Retina Display adapter sleeve Included with iDynamo 5
21041052 iPhone 3G/3GS adapter sleeve Included with iDynamo
21041050 iPhone 4/4S adapter sleeve Included with iDynamo
21041088 iPhone 5 adapter sleeve Included with iDynamo 5
21041089 iPod Touch 5th generation adapter sleeve Included with iDynamo 5
21041053 iPod Touch clip (for use with 21041052) Included with iDynamo
21051543 Retractable Micro-USB cable Optional
