41
APPENDIX C. TROUBLESHOOTING GUIDE
REQUIREMENTS
•
Personal Computer.
•
USB Cable, P/N 22517582, or 22517583
•
AC adapter, P/N 64300050.
USB Driver, on a CD P/N 30035077, from the MagTek web site P/N 99510038
.
•
MICRbase program, P/N 22000021.
•
Sample checks, P/N 96530005.
•
A small bottle of compressed air.
•
A cleaning card, P/N 96700006.
SET-UP
1. Ensure the USB Driver is installed (see Section 2 for details).
2. Plug the USB Interface Cable into the MICR and the host, 9-pin Mini Din, Male, USB A
Plug, 6’, Part Number 22517582, or Part Number 22517583.
3. Power on the MICR Reader.
4. Run the MICRbase program on the PC.
5. Press to establish communication between the PC and the MICR Reader.
6. Start trouble-shooting procedure at Step 00.
00 CHECK
LED
Check the status of the LED indicator:
◊ off, continue to step 01.
◊ green, continue to step 02.
◊ blinking red, continue to step 11.
◊ blinking green, continue to step 16.
◊ blinking red/green, continue to 12.
◊ red or orange, continue to step 17.
