3
SECTION 2. INSTALLATION
The installation for the MICR Reader is as follows:
REQUIREMENTS
The following is required for the Installation:
•
MINI MICR USB With Optional MSR
•
Interface Cable, 9-pin Mini Din, Male, USB A Plug, 6’, Beige, Part Number 22517582, or
•
Interface Cable, 9-pin Mini Din, Male, USB A Plug, 6’, MT Gray, Part Number 22517583
•
AC Power Adapter with Cable, 120VAC to 12 VAC, 1 Amp, Part Number 64300050
•
Master USB Driver P/N On a CD (Part Number 30035077) or from the MagTek web site
(
www.magtek.com ) (Part Number 99510038 ).
PROCEDURE
Perform the following steps:
1.
On the interface cable connect the USB A connector to the PC.
2. On the interface cable connect the 9-pin male DIN connector to the MICR Reader.
3.
On the AC power adapter, connect the jack to the plug on the MICR Reader.
4.
On the AC power adapter, connect the plug to the wall outlet.
5.
The first time the Reader is connected to the PC, Windows will need to install the USB
driver. See the instructions below.
6.
The LED indicator on the MICR Reader should turn on to a steady green. The LED
indicator is located below the slot where the check is first inserted for reading.
Caution
Do not place the MICR Reader within 6 inches of a computer
monitor or power supply. These devices may cause undesirable
interference with the check reading operation.
