Section 5. Troubleshooting
43
5.
Rotate the tool 90
° downward as indicated in Figure 5-3
Figure 5-3. CET Rotation
6.
Pull the tool until the card can be removed as indicated in Figure 5-4. If tool does not
capture the card edge, the tool may be under instead of above the card. Reinsert the tool
and rotate the handle 90
0
upward.
Figure 5-4. CET Extraction
7 Repeat 3 through 7 until card edge is captured. Pull the tool out until the card can be
removed. Remove the card before removing the tool.
Caution
The card and tool can not be removed together and if forced,
damage may occur to the card, the unit, or the tool.
8.
Rotate the tool to the horizontal position and remove it from unit.
9.
Turn the power on.
