EN - English - I
nstruc
tions manual
9
9.1.2 Mechanical
3xM16 cable glands
Glass window (WxH): 94x80mm (3.7x3.1in)
Internal usable area (WxH): 134x88mm (5.1x3.5in)
Internal usable area with double or triple heater (WxH):
100x88mm (3.9x3.5in)
Unit weight: 4.1kg / 9.0lb
Internal usable length without accessories
HEG47 450mm (17.7in)
Internal usable length with accessories
HEG37 273mm (10.8in)
HEG47 363mm (14.3in)
9.1.3 Electrical
Heater Ton 15°C±3°C (59°F ±37°F) Toff 22°C±3°C (71°F
±37°F)
- IN 12Vdc/24Vac, consumption 20W max
- IN 115/230Vac, consumption 40W max
- IN 115/230Vac, double heater, consumption 80W
max
- IN 115/230Vac, fan assisted triple heater,
consumption 120W + 4W max
Blower with thermostat Ton 35°C±3°C (95°F±37°F) Toff
20°C±3°C (71°F±37°F) for version with double filter
- IN 12Vdc, consumption 4W max
- IN 24Vac, consumption 4W max
Camera power supply
- IN 100-240Vac - OUT 12Vdc, 50/60 Hz, 1A
- IN 230Vac - OUT 24Vac, 50/60Hz, 400mA
9.1.4 Environment
Indoor / Outdoor
Operating temperature with heater: -20°C / +60°C (-4°F
/ +140°F)
Operating temperature with double heater: -40°C /
+60°C (-40°F / +140°F)
Operating temperature with triple heater: -50°C / +60°C
(-58°F / +140°F)
Resistant to salty fog until 1000 hours (according to
ISO9227)
9.1.5 Certifications
HEG
CE EN61000-6-3, EN60065, EN50130-4
IP66/IP67 EN60529 with cable glands
IP44 EN60529 with cooling blower and double filter
VIP6A
CE EN61000-6-3, EN60065, EN50130-4
IP66 EN60529
7 Maintaining and cleaning
7.1 Window and plastic cover
cleaning (PC)
We suggest to use neutral soap diluted with water
or specific products for lens cleaning applied with a
soft cloth.
h Avoid ethyl alcohol, solvents, hydrogenated
hydrocarbide, strong acid and alkali. Such
products may irreparably damage the
surface.
8 Disposal of waste
materials
n This symbol mark and recycle system
are applied only to EU countries and not
applied to the countries in the other area of
the world.
Your product is designed and manufactured with
high quality materials and components which can be
recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life, should be disposed of
separately from your household waste.
Please dispose of this equipment at your local
Community waste collection or Recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.
9 Technical data
9.1.1 General
Aluminium back and front cover plates
Extruded aluminium body and external slide
Epoxypolyester powder painting, RAL9002 colour
Stainless steel external screws
Supplied with instruction manual, desiccant bag,
accessories for camera and lens mounting
