13
9.3.4 Environment
Indoor / Outdoor
Operating temperature with heater: -55°C / +60°C (-67°F
/ +140°F)
Very good resistance to the following chemical agents:
basics, alcohols, gasses, hydrocarbon
Good resistance: organic and inorganic acids, oils
Low resistance: solvents
9.3.5 Certifications
CE EN61000-6-3, EN60950-1, EN50130-4
IP66/IP67 EN60529 with cable glands
IP66/IP67 EN60529 with special gaskets and bracket with
internal cable channel
IP55 EN60529 with bracket with internal cable channel
V1 fire-self extinguish compliance UL94
Impact resistance IK10 EN62262
10 Technical drawings
g j The values are in millimeters.
270 70
70
77
100
26
156
15
101
113
466
B
B
A
A
A - A B - B
USABLE
AREA
USABLE AREA
Fig. 16 VERSO
9.3 VERSO POLAR
9.3.1 General
Entirely constructed from technopolymer
(polycarbonate)
Sunshield in ABS
RAL9002 Colour
Stainless steel external screws
Supplied with instruction manual, desiccant bag,
accessories for camera and lens mounting
9.3.2 Mechanical
3xM16 cable glands in nickel-plated brass
Polycarbonate window (WxH): 105x64mm (4.1x2.5in)
Internal usable area (WxH): 70x70mm (2.7x2.7in)
Internal usable length with and without accessories:
270mm (10.6in)
Unit weight: 1.5kg / 3.3lb
9.3.3 Electrical
Heater Ton 15°C±3°C (59°F ±37°F) Toff 22°C±3°C (71°F
±37°F)
- IN 12Vdc/24Vac, consumption 60W max
- IN 115/230Vac, consumption 120W max
Camera power supply
- IN 100-240Vac - OUT 12Vdc, 50/60 Hz, 1A
- IN 230Vac - OUT 24Vac, 50/60Hz, 400mA
