EN - English - I
nstruc
tions manual
12
9.2 VERSO COMPACT
9.2.1 General
Entirely constructed from technopolymer
(polycarbonate)
Sunshield in ABS
RAL9002 Colour
Stainless steel external screws
Supplied with instruction manual, desiccant bag,
accessories for camera and lens mounting
9.2.2 Mechanical
2xM16 cable glands
Polycarbonate window (WxH): 98x55mm (3.9x2.2in)
Internal usable area (WxH): 63x63mm (2.5x2.5in)
Internal usable length with and without accessories:
210mm (8.3in)
Unit weight: 1.1kg / 2.4lb
9.2.3 Electrical
Heater Ton 15°C±3°C (59°F ±37°F) Toff 22°C±3°C (71°F
±37°F)
- IN 12Vdc/24Vac, consumption 20W max
- IN 115/230Vac, consumption 40W max
Heater fan assistant, continuous duty
- IN 12Vdc, consumption 4W max
- IN 24Vac, consumption 4W max
- IN 100-240Vac, consumption 4W max, with wide
range power supply IN 100-240Vac/12Vdc
Camera power supply
- IN 100-240Vac - OUT 12Vdc, 50/60 Hz, 1A
- IN 230Vac - OUT 24Vac, 50 Hz, 400mA
9.2.4 Environment
Indoor / Outdoor
Operating temperature with heater: -20°C / +60°C (-4°F
/ +140°F)
Very good resistance to the following chemical agents:
basics, alcohols, gasses, hydrocarbon
Good resistance: organic and inorganic acids, oils
Low resistance: solvents
9.2.5 Certifications
CE EN61000-6-3, EN60950-1, EN50130-4
IP66/IP67 EN60529 with cable glands
IP66/IP67 EN60529 with special gaskets and bracket with
internal cable channel
IP55 EN60529 with bracket with internal cable channel
V1 fire-self extinguish compliance UL94
Impact resistance IK10 EN62262
9.1.2 Mechanical
3xM16 cable glands
Polycarbonate window (WxH): 105x64mm (4.1x2.5in)
Internal usable area (WxH): 70x70mm (2.7x2.7in)
Internal usable length with and without accessories:
270mm (10.6in)
Unit weight: 1.5kg / 3.3lb
9.1.3 Electrical
Heater Ton 15°C±3°C (59°F ±37°F) Toff 22°C±3°C (71°F
±37°F)
- IN 12Vdc/24Vac, consumption 20W max
- IN 115/230Vac, consumption 40W max
Heater fan assistant, continuous duty
- IN 12Vdc, consumption 4W max
- IN 24Vac, consumption 4W max
- IN 100-240Vac, consumption 4W max, with wide
range power supply IN 100-240Vac/12Vdc
Blower with thermostat air filter, Ton 35°C±3°C
(95°F±37°F) Toff 20°C±3°C (71°F±37°F) with wide range
power supply IN 100-240Vac - OUT 12Vdc, out 1A
- IN 110-240Vac, consumption 4W max
Blower with thermostat Ton 35°C±3°C (95°F±37°F) Toff
20°C±3°C (71°F±37°F) for version with double filter
- IN 12Vdc, consumption 4W max
- IN 24Vac, consumption 4W max
Camera power supply
- IN 100-240Vac - OUT 12Vdc, 50/60 Hz, 1A
- IN 230Vac - OUT 24Vac, 50/60Hz, 400mA
9.1.4 Environment
Indoor / Outdoor
Operating temperature with heater: -20°C / +60°C (-4°F
/ +140°F)
Very good resistance to the following chemical agents:
basics, alcohols, gasses, hydrocarbon
Good resistance: organic and inorganic acids, oils
Low resistance: solvents
9.1.5 Certifications
CE EN61000-6-3, EN60950-1, EN50130-4
IP66/IP67 EN60529 with cable glands
IP66/IP67 EN60529 with special gaskets and bracket with
internal cable channel
IP55 EN60529 with bracket with internal cable channel
IP44 EN60529 with cooling blower and double filter
V1 fire-self extinguish compliance UL94
Impact resistance IK10 EN62262
