16 Technical drawings
The dimensions of the drawings are in millimetres.
258
R369
514
90
B
B
325
130
195
A
A
A - A
B - B
73
623
743
115
90
25
13
72
5
374
R365
USABLE
AREA
USABLE AREA
USABLE AREA
Fig. 84
ULISSE PLUS NETCAM.
