8-17: Assembly drawings and Parts lists
CMX-20
Part Number Description qty
CMX-20 - 230 V Assembly Parts List (P/N 604-999-220)
000-006-009 base, w/handle - Coat 1
000-011-001 bezel, Threaded for 000-157-134 1
000-015-006 bracket, head Stabilizer 1
000-015-139 bracket, handle-To-base 1
000-015-190 bracket, Relay Mount 1
000-015-552 bracket, linkage Clamp 2
000-033-010 Clamp, Size 32 hose 2
000-033-114 Clamp, Linkage - Modified 1
000-041-013 Cover, handle Access 1
000-041-352 Cover, linkage Clamp 1
000-049-033 filter,1/4” Inline y 1
000-052-001 fitting, Swivel, 2M-2UfS 2
000-052-050 1/4” Male Quick Connector 1
000-052-059 bushing,1/4 M X 1/8 2
000-052-071 Nipple,1/4 brass hex 1
000-052-072 Nipple,1/4 brass Close 1
000-052-085 Elbow,1/4”brass Street 1
000-052-294 Rotary Union, brass 1
000-056-009 fuse, 6.3 Amp 5mm X 20 2
000-059-001 gear box Complete 1
000-061-004 handle, foam grip-Closed 2
000-061-030 handle, Clamp “T” (Raw) 2
000-061-119 Knob, Push button 1
000-068-176 Hose, 3/16”X 45” Teflon 1
000-068-193 hose, 2” Clear Vacuum 2.8 ft
000-081-102 label, 230 V CE 1
000-091-016 Motor, 1/2 hP TEfC-22 1
000-094-030-07 Nut, Adjusting, linkage 1
Part Number Description qty
000-103-012 Pin, 1/4 X 7/8” Clevis 2
000-105-008 Plate, Cast base 1
000-106-001 Plug,1/8” brass 1
000-106-014 Plug, gear box Vent 1
000-106-109 Plug, 230 V IEC w/fuse Receptacle 1
000-107-096 handle Arc 2
000-107-097 link 4
000-107-103 Trigger Pivot 1
000-107-256 Plunger, locking 2
000-108-014 Shield, Micro Switch 1
000-131-014 gasket, Roto Shroud 3.3 ft
000-139-006 Ring, 5/8” Snap 2
000-141-004 Axle, hi Speed Wheel 1
000-141-007 Rod Assembly, handle Adj. Clamp 1
000-141-031 Rod, handle Arc 1
000-143-609 Screw, 5/8-18 X 5/8 lg 2
000-156-031 1/4-20 X 1” S/S 1
000-157-132 Relay, 230 V 30 Amp SPST 1
000-157-133 Switch, 230 V 1
000-157-134 Switch, 230 V Momentary 1
000-167-009-07 Trigger, left hand 1
000-167-010-07 Trigger, Right hand 1
000-169-058 Valve, S/S 1
000-174-030 Washer, 5/8” I.d. X 7/8” 2
000-177-001 Wheel, 8” hi Speed 2
000-178-054 Cord, 50’ w/M-f IEC Ends 230 V 1
604-051-019 handle, Powder Coated 1
604-053-002 dble.Thread Vac. head 1
