Assembly drawings and Parts lists: 8-2
CMX-20
Table 8-1.
CMX-20 Configurations
CMX-20 Top Level P/N Top Level Assembly Parts List See This Page for
Detailed Parts List P/N Description qty
CMX-20 - 120 V 700-041-008 000-057-047 gasket, felt hub 2
000-081-351 label,CMX-20 1
000-105-018 Plate, Serial I.d. 1
604-999-004 CMX-20 - 120 V final Assembly 1
Page 8-16
604-999-004
120 V final Assembly
CMX-20 - 230 V 700-041-009 000-057-047 gasket, felt hub 2
000-081-351 label,CMX-20 1
000-105-018 Plate, Serial I.d. 1
604-999-220 CMX-20 - 230 Volt final Assembly 1
Page 8-17
604-999-220
230 V final Assembly
