U.S. Products CMX-20 ROTARY EXTRACTOR - Manual (Page 37)

8-7: Assembly drawings and Parts lists
CMX-20
Upper and Lower Handle Assembly Parts List
Item Part Number Description qty Item Part Number Description qty
1 000-107-096 handle, Arc 2
2 000-107-103 Trigger Pivot 1
3 000-105-007 Plate, back - handle 1
4 000-169-058 Valve, S/S Solution 1
5 000-154-001 Spacer, 1/4” X 5/16” - S/S Solution Valve 2
6 000-108-014 Shield, Micro Switch 1
7 000-141-004 Axle, Wheel 1
8 000-105-018 Plate, Serial I.d. 1
9 000-015-987 bracket, linkage Clamp 2
10 000-141-007 Adjusting Rod Assembly 1
11 000-015-190 bracket, AC Relay 1
12 000-061-030 handle, ‘T’ handle 2
13 000-033-114 Clamp, Linkage - Modified 1
14 000-141-031 Rod, handle Arc 1
15 000-015-139 bracket, hi Speed handle To base Weldment 1
16 000-015-006 bracket, head Stabilizer - Weldment 1
17 000-061-017 handle, hi Speed (120 V Version Only) 1
604-051-019 handle, hi Speed (230 V Version Only) 1
18 000-177-001 Wheel, 8” 2
19 000-139-009 Ring, Snap (E-Clip) X 1/2” 2
21 000-052-050 Quick Connect, 440 Male w/ Viton Std 1
22 000-052-059 bushing, 1/4” MPT X 1/8” fPT 1
22 000-061-004 grip, foam - handle 2
23 000-052-071 Nipple, 1/4” NPT hex 1
24 000-052-072 Nipple, 1/4” NPT Close 1
25 000-052-085 Elbow, 1/4” NPT Street 1
26 000-049-033 filter, In-line, “y” 1
27 000-157-151 Switch, Chrome, Momentary (120 V Version Only) 1
000-157-134 Switch, 230 V Momentary (230 V Version Only) 1
28 000-157-149 Relay, AC Relay 120 V (120 V Version Only) 1
000-157-132 Relay, 230 V 30 Amp SPST (230 V Version Only) 1
29 000-157-032 Switch, Micro (120 V Version Only) 1
000-157-133 Switch, 230 V (230 V Version Only) 1
30 000-108-012 Protector, Power Cord Relief (120 V Version Only) 1
31 000-174-001 Washer, #10 flat 1
32 000-156-031 Stud, 1/4”-20UNC X 1.00” lg. 1
33 000-143-048 Screw, #10-24UNC X 0.25” lg. Pan head Phillips 2
34 000-094-034 Nut, #10-24UNC Nylock 7
35 000-143-166 Screw, #10-24UNC X 3/8” lg. hex head 7
36 000-052-001 fitting, Swivel (2M2-2 UfS) 1
37 000-143-002 Screw, 1/4”-20UNC X 1.00” lg. hex head 3
38 000-094-036 Nut,1/2” NPT Pipe Plastic (120 V Version Only) 1
39 000-143-065 Screw, #10-24UNC X 1.75” lg. hex head 1
40 000-139-010 Ring, Snap (E-Clip) X 5/16” 4
41 000-174-006 Washer, 7/16” flat 2
42 000-143-126 Screw, #10-24UNC X 0.50” lg. hex head 5
43 000-143-107 Screw, #10-24UNC X 3/8”” lg. button head Socket 4
44 000-094-009 Nut, 1/4”-20UNC Nylock 1
45 000-040-003 Rivet, 1/8” X 5/16” 2
46 000-178-039 Cord, Power - 14/3 gray X 42” w/ female
(120 V Version Only) 1
47 000-178-004 Cord, Power 14/3 gray X 50’ w/ Male
(120 V Version Only) 1
000-178-054 Cord, 50’ w/M-f IEC Ends 230 V
(230 V Version Only) 1
48 000-094-063 Nut, #6-32UNC Nylock 2
49 000-143-575 Screw, #6-32UNC X 0.50” lg. hex head 2
50 000-167-009-07 Trigger, handle - left hand 1
51 000-167-010-07 Trigger, handle - Right hand 1
52 000-143-609 Screw, 5/8-18 X 5/8lg, Socket hd Set 2
53 604-051-002 Assembly, handle locking linkage 1
54 000-041-352 Cover, linkage Clamp 1
