8-15: Assembly drawings and Parts lists
CMX-20
Vacuum Shoe and Skid (Original Style) Assembly figure 8-11.
6387
4
1
2
3
Vacuum Shoe and Skid (Original Style) Assembly Parts List
1 000-064-011 4” Vac head - Weldment 1
2 000-057-048 gasket, Vacuum head 1
3 000-107-095 Skid, Wire 1
4 000-094-058 Nut, #10-32UNf - Nylock 2
Item Part Number Description qty
