22 www.teledex.com Y SERIES EXP212, EXP224, AND EXP248 USER GUIDE
2. The EXP248 provides two firmware
memory partitions. If you want to change
the firmware partition for booting, use the
following commands (if you change to the
non-active partition, system will restart
immediately):
enable //go to enable mode
configure //go to configuration mode
firmware partition //select
partition 1 or 2 for next power-on
IN WEB
On the menu tree, click on Maintenance --- >
Firmware Update. The Firmware Update page
is displayed. Once you have entered all the
necessary values, click on
Firmware Update
button to start updating the firmware.
Label Description
Firmware
Update Once you have typed in the
parameter values, click on
this button to start firmware
update.
Remote FTP
Server IP Type in the IP address of the
FTP server.
Server User
Name Type in the FTP user name.
Server
Password Type in the FTP password.
File Name Type in the firmware filename.
Firmware
Update Status This field shows current status
of firmware update process.
Firmware
Partition
Select Select firmware memory
partition (Partition 1 or 2).
If you change to the other
partition (not current partition),
the system will restart
immediately.
Partition
Information This section displays the
partition information including
firmware version, updating
date, and status (active or
not). Note that active partition
means the partition for
next power-up, not current
partition in use. You can refer
to
Current Version to know
which partition is the current
partition in use. When you
update the firmware, new
firmware will be written to the
partition that is not currently in
use.
FTP Get In Progress
The following message is displayed during getting
file from FTP server.
