12 www.teledex.com Y SERIES EXP100 USER GUIDE
The following screen shows the WAN setup
screen.
5.1 ATM Interface
Add or remove ATM interface connections here.
NOTE: Up to 8 ATM interfaces can be created and
saved in flash memory.
To remove a connection, select its Remove
column radio button and click
Remove.
5.2 WAN Service
This screen allows for the configuration of WAN
interfaces.
Click the Add button to create a new connection.
To remove a connection, select its Remove
column radio button and click
Remove.
Heading Description
Interface Name of the interface for WAN
Description Name of the WAN connection
Heading Description
Type Shows the connection type
Vlan8021p VLAN ID is used for VLAN
Tagging (IEEE 802.1Q)
VlanMuxId Shows 802.1Q VLAN ID
IGMP Shows Internet Group
Management Protocol (IGMP)
status
NAT Shows Network Address
Translation (NAT) status
Firewall Shows the security status
Connect/
Disconnect Shows the connection status
Remove Select interfaces to remove
To remove a connection, select its Remove
column radio button and click
Remove.
To Add a new WAN connection, click the Add
button and follow the instructions.
NOTE: Up to 16 PVC profiles can be configured
and saved in flash memory. Also, ATM and PTM
service connections cannot coexist.
5.3 Interface Grouping
Interface Grouping supports multiple ports to
PVC and bridging groups. Each group performs
as an independent network. To use this
feature, you must create mapping groups with
appropriate LAN and WAN interfaces using the
Add button.
The
Remove button removes mapping groups,
returning the ungrouped interfaces to the
Default group. Only the default group has an IP
interface.
Chapter 5 WAN Setup
