Chapter 2 WINBIOS Setup 47
Standard Setup, Continued
Pri Master, Pri Slave, Sec Master, Sec Slave Select one of these hard disk drive icons to
configure the hard disk drive named in the option. Select Auto from the drive
parameters screen to let AMIBIOS automatically configure the drive. A screen
with a list of drive parameters appears. Click on OK to configure the drive.
Drive Type How to Configure
SCSI Select Type. Select SCSI in the drive parameter screen. The SCSI drivers
provided by the SCSI drive or SCSI host adapter manufacturer should allow
you to configure the SCSI drive.
IDE Select Type. Select Auto to let AMIBIOS determine the parameters. Click
on OK when AMIBIOS displays the drive parameters.
Select LBA/Large Mode. Select On if the drive has a capacity greater
than 540 MB.
Select Block Mode. Select On to allow block mode data transfers.
Select 32-Bit Transfer. Select On to allow 32-bit data transfers.
Select the PIO Mode. It is best to select Auto to allow AMIBIOS to
determine the PIO mode. If you select a PIO mode that is not supported by the
IDE drive, the drive will not work properly. If you are absolutely certain that
you know the drive’s PIO mode, select PIO mode 0 - 5, as appropriate.
CD-ROM Select Type. Select CDROM . Click on OK when AMIBIOS displays
the drive parameters.
Standard MFM
Drive
Select Type. You must know the drive parameters. Select the drive type that
exactly matches your drive’s parameters.
Non-Standard
MFM Drive
Select Type. If the drive parameters do not match the drive parameters listed
for drive types 1 - 46, select User and enter the correct hard disk drive
parameters.
Cont’d
