MegaRUM PCI Motherboard User’s Guide 34
Step 10 Connect I/O, Continued
J11 Pinout J11 is the secondary IDE connector. The J11 pinout is:
Pin Use Pin Use
1 -RESET 2 GND
3 DATA7 4 DATA8
5 DATA6 6 DATA9
7 DATA5 8 DATA10
9 DATA4 10 DATA11
11 DATA3 12 DATA12
13 DATA2 14 DATA13
15 DATA1 16 DATA14
17 DATA0 18 DATA15
19 GND 20 KEY (N/C)
21 -REQ 22 GND
23 -IOW 24 GND
25 -IOR 26 GND
27 IDERDY 28 Pulldown
29 -ACK 30 GND
31 INT15 32 N/C
33 HA1 34 N/C
35 HA0 36 HA2
37 -CS2 38 -CS3
39 N/C 40 GND
