MegaRUM PCI Motherboard User’s Guide 20
Step 9 Attach Cables, Continued
P2 Pinout
Pin Description
1 5V
2 5V
3 5V
4 Ground
5 Ground
6 Ground
P4 Pinout
Pin Description
1 3V
2 3V
3 3V
4 Ground
5 Ground
6 Ground
J35 Erase Password J35 is a 2-pin berg that can be used to erase the contents of CMOS RAM,
where all system configuration information is stored.
If you forget the AMIBIOS password, you can place a shorting bridge on J35
for a few seconds to erase the old password (and all system configuration
information as well). You must then reboot the computer, run AMIBIOS Setup,
and restore all system configuration information. The J35 settings are:
CMOS Drain J35 Setting
Normal operation (factory setting). OPEN
The contents of CMOS RAM are destroyed. Shorted
Cont’d
