MegaRUM PCI Motherboard User’s Guide 28
Step 10 Connect I/O, Continued
J3 Parallel Port J3 is a 25-pin connector for a parallel port. The J3 pinout is shown below.
Connect the 16-pin to DB25 cable provided with the motherboard to J3. The
parallel port interface supports:
•
the standard Centronics-compatible parallel port,
•
the ECP (Extended Capabilities Port), and
•
the EPP (Enhanced Parallel Port) port.
All parallel port settings must be correctly configured through Peripheral Setup
in WINBIOS Setup.
Pin Signal
Description
Pin Signal Description
1 STROBE# 2 PD0
3 PD1 4 PD2
5 PD3 6 PD4
7 PD5 8 PD6
9 PD7 10 ACK#
11 BUSY 12 PE
13 SLCT 14 AUTOFD#
15 ERROR# 16 INIT#
17 SLCTIN# 18 Ground
19 Ground 20 Ground
21 Ground 22 Ground
23 Ground 24 Ground
25 Ground 26 Ground
Cont’d
