English | 13
"X'OVER"
Sound Management Item Range
Front High Pass Filter Cut off Frequency/
Rear High Pass Filter Cut off Frequency Through/ 30 — 100/ 120/
150/ 180/ 220/ 250 (Hz)
Front High Pass Filter Slope/
Rear High Pass Filter Slope/
Subwoofer Low Pass Filter Slope -12/ -18/ -24 dB/Oct
Subwoofer Low Pass Filter Cut off
Frequency 30 — 100/ 120/ 150/ 180/
220/ 250 (Hz)/ Through
Subwoofer Low Pass Filter Phase Normal/ Reverse
4 Exit Sound Management mode
Press the [FNC] button.
Position Control
1 Enter Position mode
Using the Control knob, select "DSP" > "SND
CONT" > "POSITION".
For the operation method, refer to Control mode> (page 11).
2 Select the Position item to adjust
Turn the Control knob or push it towards left
or right.
Icon Position Item
"PRESET" Preset Position
"MANUAL" Manual Position
3 Enter the Position item
Press the Control knob.
4 Adjust the Position item
Preset Position Setting
Push the Control knob towards right or left.
Each time you push the knob, the setting alternates
between the settings shown in the table below.
Range
All/ Front-Left/ Front-Right/ Front
Manual Position Setting
1 Select the items to adjust for Position.
Push the Control knob towards up or down.
Display Position Item
"L" "FRONT" Front Left
"L" "REAR" Rear Left
"L" "SW" Subwoofer Left
"FRONT" "R" Front Right
"REAR" "R" Rear Right
"SW" "R" Subwoofer Right
2 Adjust the Position.
Turn the Control knob or push it towards left
or right.
Each time you push the knob, the setting
alternates between the settings shown in the
table below.
Range
0 — 100 (cm)
5 Exit Position mode
Press the [FNC] button.
⁄
• About the position setting
First, set the using environment with “DTA” in
Management system> (page 12).
Preset position setting is for selecting the actual listening
position.
Manual position setting is for further adjustment of the
position selected in preset position setting. This setting
value can be memorized for each preset position.
• When using the Subwoofer Left and Subwoofer Right as
a single sub woofer, set the left side and right side to the
same value.
• Preset Position initial settings
Preset Position Front Rear Subwoofer
Left Right Left Right Left Right
ALL 0 0 0 0 0 0
Front-Left 0 35 0 35 0 0
Front-Right 35 0 35 0 0 0
Front 0 0 100 100 0 0
