Product Line Information
LCD-160: 640-character Liquid Crystal Display annunciator.
Backboxes
The following backboxes can be surface- or semi-flush-
mounted to provide an enclosure for remote mounting. Use
with 1/2" (1.27 cm) conduit in the provided knockouts.
ABS-2D (black) and ABS-2DR (red): Surface- or semi-flush
enclosure for remote mounting. Mounts an LCD-160 directly to
the enclosure’s hinged dress plate. The ABS-2D and ABS-
2DR do NOT support the installation of the AKS-1B key-
switch. Not for use in Canadian applications. Optional trim ring
TR-ABS2D for semi-flush mounting. Dimensions, box: 12.0"
(30.480 cm) H x 12.0" (30.480 cm) W x 3.797" (9.644 cm) D
(NOTE: The black ABS-2D is slightly deeper). Dimensions,
door:
12.0" (30.480 cm) H x 12.0" (30.480 cm) W x 1.250"
(3.175 cm) D.
ABS-4D (black) and ABS-4DR (red): Surface- or semi-flush-
enclosure for remote mounting. Mounts an LCD-160 and two
annunciators directly to the enclosure’s hinged dress plate.
The ABS-4D and ABS-4DR do NOT support the installation of
the AKS-1B key-switch. Dimensions, box: 11.97" (30.40 cm)
H x 19.87" (50.47 cm) W x 3.5" (8.89 cm) D. Dimensions,
door:
11.97" (30.40 cm) H x 19.87" (50.47 cm) W x 1.250"
(3.175 cm) D.
ABF-2B: Black flush enclosure for remote mounting. Mounts
an LCD-160 directly to the enclosure’s dress plate. Not for use
in Canadian applications. Includes a painted black metal trim
plate [11" (27.94 cm) high x 10.625" (26.99 cm) wide] and
adhesive-backed annunciator label. 9.938" (25.24 cm) high x
9.188" (23.34 cm) wide x 3.75" (9.525 cm) deep.
ABF-2DB: Black flush enclosure for remote mounting. Mounts
an LCD-160 directly to the enclosure’s dress plate. Does not
support the installation of AKS-1B. Box dimensions: 9.938"
(25.24 cm) high x 9.188" (23.24 cm) wide x 3.75" (9.525 cm)
deep.Door dimensions: 11" (29.94 cm) high x 10.375" (26.35
cm) wide x 0.75" (1.9 cm) deep.
ABF-4B: Black flush enclosure for remote mounting of one
LCD-160 and two annunciator modules directly to the enclo-
sure’s dress plate. Knockouts are provided for use with 1/2"
(1.27 cm) conduit. Includes a painted black metal trim plate
[11" (27.94 cm) high x 19.375" (49.21 cm) wide] and an annun-
ciator label. 9.938" (25.24 cm) high x 17.75" (45.09 cm) wide x
2.5" (6.35 cm) deep.
CAB-4 Series cabinets: Surface- or semi-flush-mounted, in
sizes to accommodate one to four rows of equipment plus bat-
teries (up to two 26 AH batteries). Four sizes are available.
Doors are ordered separately, and feature reversible hinges to
mount doors on the left or right side. Doors also open a full
180°. Keylocks are included. For dimensions and further infor-
mation, see datasheet DN-6857.
ACCESSORIES
DP-DISP: Dress Panel Display for cabinet mounting of an
LCD-160. LCD-160 mounts directly to the dress panel, which
hinge-mounts to the top tier of a CAB-4 Series backbox.
ADP-4B: Annunciator Dress Panel-4B (black) for cabinet
mounting of an LCD-160. LCD-160 mounts directly to the
dress panel, which hinge-mounts to the tier of a CAB-4 Series
backbox.
TR-ABS2D: Optional trim ring for semi-flush mounting ABS-
2D(R).
VP-2B: Vented Dress Panel for use with the ADP-4B dress
panel installed in the top tier of a NOTIFIER cabinet. It covers
the gap between the dress panel and top of the cabinet.
AKS-1B: Annunciator Key Switch provides access security for
the control switches on the LCD-160. Key-switch kit includes
key, hardware, and an annunciator label.
