Dake Model Super Technics 350SA - Manual (Page 17)

17
SUPER SUPER SUPER SUPER SUPER TECHNICS 350 SA TECHNICS 350 SA TECHNICS 350 SA TECHNICS 350 SA TECHNICS 350 SA
10
MACHINE COMPONENTS
10.1 - List of spare parts
2 Revolving arm
3
4
5
6
7 Countervice
8 Mobile countervice
9 Countervice jaws
10 Burr-free jaws
11 Countervice rotation
locking pin
12
13
14
15
16
17
18 Vice jaws
19 Vice jaw washer
20 Screw M12
21 Washer
22 Screw M12
23
24
25
26
27
28
29
30
31
32 Vice gib
33 Grain M8
34 Nut M8
35 Vice thread
36 Quick lock vice spring
37 Burr-free transverse plate
38 Burr-free plate
39
40 Screw M8
41
42
43
44
45
46
47 Oiler Ø 8
48 Grain M8
49
50
57 Extra shield
58 Spring connection
59 Head return spring
60 Nut M12
61 Screw M12
62 Head
63 3/8 gas tap
64 GUK M25x1,5 ring nut
65 Spring thrusting washer
66 Oil level and drain plug 1/2 gas
67 Hinge cylindrical pin
68 GUK M25x1,5 ring nut
69 Hinge eccentric pin
70 Eccentric bush
71 Bearing 6202
72
73
74
75 Bush
76 Bearing 32008X
REFERENCE N° DESCRIPTION REFERENCE N° DESCRIPTION
