Ga-k8nsc-939 motherboard layout, Ga-k8nsc-939 – AMD GA-K8NSC-939 User Manual
Page 6
- 6 -
GA-K8NSC-939 Motherboard Layout
DDR1
DDR2
DDR3
DDR4
ATX_12V
CPU_FAN
NB_FAN
CODEC
IR_CIR
IT8712
nVIDIA
®
nForce
TM
3 250Gb/
250 Ultra
BIOS
PCI1
PCI2
F_USB2
F_USB1
SATA1_SB
SATA0_SB
BATTERY
ATX
IDE2
FDD
CLR_CMOS
SYS_FAN
GA-K8NSC-939
KB_MS
Socket 939
AUDIO
COMB
LPT
USB
USB
LAN
F_AUDIO
CD_IN
F_PANEL
PWR_LED
COMA
IDE1
PCI3
PCI4
Marvell
8001
SUR_CEN
SPDIF_IO
PCI5
AGP
