VM-Series Multiplexer User Manual 20/02/2002 12:00
Videoswitch
17 VM601h.doc
Auto Colour/Mono The mode or mono/colour switching cameras may be
set here. Note that OFF toggles colour/mono while
ON sets camera to AUTO.
Zoom Rate The rate of zoom may be programmed here using
п р. Press BACK to finish.
Focus Rate The rate of focus may be programmed here using
п р. Press BACK to finish.
Iris Rate The rate of iris may be programmed here using
п р. Press BACK to finish.
User Command Additional dome commands may be programmed
here in hexadecimal. Use
п р с т SELECT
and BACK.
Receiver Video Gain The video gain of a receiver may be set here using
п р. If control of receiver is lost, set gain to
appropriate level and wait up to 30s to regain control.
Press BACK to finish
Receiver Video Lift The high frequency lift (compensation) of a receiver
may be set here using
п р. Wait up to 30s for lift
wo reach required setting. Press BACK to finish.
VP-1/VP-1A Preset Dwell Press ENTER to start timer. Press BACK when
required preset dwell time has elapsed.
VP-1A Alarm Dwell Press ENTER to start timer. Press BACK when
required alarm dwell time has elapsed.
VR Receiver Training Press ENTER to start receiver training. Press BACK
when complete.
Program Presets Store the current camera position as a preset in a
dome or telemetry receiver. Use
с т. Press SET to
store preset. Press BACK to finish.
Program Tour A tour may be programmed here. After exiting the
menu, use AUX5 to invoke the tour.
Create New Tour Press SEL then use с т to select a preset. Press
SEL again. Press BACK to finish.
Dwell Specify how long you want this preset to be held in
the tour. Use
с т. Press BACK to finish.
Pan Rate The pan speed between presets may be
programmed here using
п р. Press BACK to
finish.
Tilt Rate The tilt speed between presets may be programmed
here using
п р. Press BACK to finish.
Add to tour? Press SEL to add this preset to the tour. Press BACK
to finish.
Power-up States Following a power loss, the the display mode and
PLAY mode may be specified.
Monitor A
Display Mode Select the display mode you require following power
up. Use
с т. Press BACK to finish.
Full Screen Camera Select the full screen camera you require (if
applicable) following power up. Use
с т. Press
BACK to finish.
Auto Sequencing Specify whether you want auto sequencing following
power up. Use
с т. Press BACK to finish.
Monitor B
Display Mode Select the display mode you require following power
up. Use
с т. Press BACK to finish.
Full Screen Camera Select the full screen camera you require (if
applicable) following power up. Use
с т. Press
BACK to finish.
Auto Sequencing Specify whether you want auto sequencing following
power up. Use
с т. Press BACK to finish.
Picture in Picture Camera Select the PIP camera you require (if applicable)
following power up. Use
с т. Press BACK to
finish.
Play Mode Specify whether you want the multiplexer to go into
PLAY mode following power up. Use
с т. Press
BACK to finish.
