5.3 Installer Menu
The options appearing in this menu are shown in this table. Note that some options are not applicable to all
multiplexer models. Press and hold the PLAY key to set any option to its default state.
Sub-Menus & Options
Press SELECT to enter option, then do the following:
Time Lapse Modes
Normal Select the time-lapse mode required when there is
not an alarm using
с т. Press BACK to finish.
Alarm Select the time-lapse mode required when there is an
alarm using
с т. Press BACK to finish.
Special Multiplex Options
VCR Sampling Mode Use this option to specify whether an older Sony or
Sanyo VCR is being used with irregular field
sampling. Use
с т. Press BACK to finish.
VCR Sync Input Some VCR sync outputs require a pull-up resistor. If
the multiplexer is not detecting the sync pulse, try
each option using
с т. Press BACK to finish.
Alarm Prioritised Using с т to select prioritised alarm recording. Any
cameras with alarms will be recorded more frequently
if this mode is selected. Note that multi-screen
update may be affected, particularly in PLAY mode,
Select full screen for maximum update rate. Press
BACK to finish.
Play-Back Compatibility Compatibility with older Series 1 monochrome
multiplexer may be selected here using
с т. Press
BACK to finish.
Custom Multiplex - Normal
Custom Multiplex - Alarm
S-Video Record/Play S-Video record and playback compatibility is selected
here using
с т. Press BACK to finish.
Multiplexer Title The multiplexer title is set character by character
using
п р с т and SELECT. Press BACK
to finish.
Camera Titles
Camera 1,2,3 etc Select the required camera using с т, then press
ENTER to continue or BACK to finish.
Title Camera titles are set character by character
using
п р с т and SELECT. Press BACK
to finish.
Text Options
Date/Time Formats The date and time formats may be set to suit your
preference, Set to off if you wish to use the VCRs
internal date and timer generator.
Use
п р с т and SELECT. Press BACK to
finish.
Show Day of Week The day of week may optionally be displayed. Select
here using
с т. Press BACK to finish.
Show Text on Monitor B Textis always displayed on monitor “A” but may
optionally be displayed on monitor “B” as well. Use
с т. Press BACK to finish.
Hide Multi-Screen Titles Titles may be suppressed in multi-screen displays in
order to reduce screen clutter. Use
с т. Press
BACK to finish.
Text Positions text position may be altered, but make sure that they
do not overlap.
Date/Time The date and time may be displayed anywhere on the
screen. Use
п р с т. Press BACK to finish.
Multiplexer Title The multiplexer title may be displayed anywhere on
the screen. Use
п р с т. Press BACK to
finish.
Camera Title The camera title (full screen) may be displayed
anywhere on the screen. Use
п р с т. Press
BACK to finish.
