The ProValve100 controller drives proportional solenoid valves. The output current is proportional to the command
input.
Once configured, the settings are permanently stored in the controller memory.
PV100 Features
 Easily configured using HCT Graphical User Interface (GUI) or HCT Hand Held Interface (HHI)
 LED indication of power, output current and fault status
 DIN-rail mount housing with removable terminal blocks
 Multiple modes for single and dual coil applications, programmable enable input
 All input and output limits are independently adjustable
 Adjustable output with short circuit protection
Operating Specifications
Supply Voltage 12 to 30VDC
Supply Current Valve current + 50mA (Quiescent Max)
Output Current Standard: 2.5A max -L: 500mA MAX -N: 250mA MAX
Coil Resistance Standard: 2Ω MIN -L: 10Ω MIN –N: 10Ω MIN
Reference Voltages -10V, +10V @ 2mA
Dither Frequency 35, 41, 49, 61, 81, 122, 244Hz
(Select OFF for PWM frequency 15.63KHz)
Two-speed Ramp Time 0.10 to 16.96 seconds
Analog Slew Time 0.1 to 30.0 seconds
Analog Input Range [0, 10]V, [-10, +10]V, [0, 5]V, [5, +5]V, [0, 20]mA
Analog Input Impedance > 100K

for voltage input
500

for current input.
Digital Input Range -24: 12 to 30VDC -115: 100 to 130VAC -230: 210 to 250VAC
Digital Input Impedance -24: 3.3k

-115: 33k

-230: 75

Operating Temperature Range 0º to 70º C (operating); -40º to 85º C (storage)
Enclosure Compact
Dimensions Inch: 3.9 L x 4.5 W x 0.4 H, Mm: 99 L x 114.5 W x 10 H
