021-PV100 Rev A PV100 User Manual 11
Copyright © High Country Tek, Inc. – 2013
PV100
Valve Controller
PV100 - The title parameter is fixed. It displays the model number and the firmware version.
MODE AI D1 D2 D3 - 8 modes of operation. AI is the analog input, D1, D2, and D3 are digital inputs. See Modes of
Operation for details.
A MINIMUM INPUT - Sets the minimum command input for coil A (0 to 100%). The value in the brackets is the
present command input.
A MAXIMUM INPUT - Sets the maximum command input for coil A (0 to 100%). The output will hold its max value
when the input is greater than this value. The value in the brackets is the present command input.
A MINIMUM OUTPUT - Sets the minimum output current for coil A (Amps). The value in the brackets is the present
output current.
A LOW/OVR OUTPUT - Sets coil A current output when low speed is chosen in digital input mode. It also sets the
current output for the forward override command in analog modes (Amps).
A MAXIMUM OUTPUT - Sets the maximum output current for coil A (Amps). The value in the brackets is the
present output current.
B MINIMUM INPUT - Sets the minimum command input for coil B (0 to -100%). The value in the brackets is the
present command input.
B MAXIMUM INPUT - Sets the maximum command input for coil B (0 to -100%). The output will hold its max value
when the input is greater than this value. The value in the brackets is the present command input.
B MINIMUM OUTPUT - Sets the minimum output current for coil B (Amps). The value in the brackets is the present
output current.
B LOW/OVR OUTPUT - Sets coil B current output when low speed is chosen in digital input mode. It also sets the
current output for the reverse override command in analog modes (Amps).
B MAXIMUM OUTPUT - Sets the maximum output current for coil B (Amps). The value in the brackets is the
present output current.
DITHER FREQ. - Set the PWM or dither frequency according to the valve specifications. This parameter is variable.
Options: 35, 41, 49, 61, 81, 122, 244, (Select OFF for 1000Hz)
INPUT SLEW TIME - Sets the rate of change of the command input for full range ramping up and down.
RAMP UP LOW - Sets the time to ramp the output from off to low speed. This parameter applies only to two-speed
modes. The Ramp Up Low parameter is variable.
