021-MVP-Cxx-(D1) Rev A MVP-C-(D1) User Manual 5
Copyright © High Country Tek, Inc. – 2013
MVP-Cxx-(D1)
Valve Controller
MVP-Cxx-(D1) Controller
The MVP-Cxx-(D1) controller drives proportional solenoid valves. The output current is proportional to the
command input.
Once configured, the settings are permanently stored in the controller memory.
MVP-C Features
 Easily configured using HCT Graphical User Interface (GUI) or HCT Hand Held Interface (HHI)
 LED indication of power, output current and fault status
 Permanently sealed, standard DIN 43650 Form A connector body with pre-wired 18AWG PVC cable
 Multiple modes for proportional or 2-speed control
 Single coil applications, programmable enable input
 All input and output limits are independently adjustable
 Adjustable output with short circuit protection, adjustable ramp up and ramp down rates
Operating Specifications
MVP-C (Standard) MVP-Cxx-xxxD1
Supply Voltage 9 to 28VDC
Supply Current Valve current + 20mA (Quiescent Max)
Output Current -06A: 600mA MAX
-12A: 1.2A MAX
-25A: 2.5A MAX
-06A: 600mA MAX
-25A: 2.5A MAX
Coil Resistance 2Ω MIN.
Reference Voltages +5V @ 2mA
Dither Frequency 30, 33, 38, 43, 50, 60, 75, 100, 150,
300Hz
(Select OFF for 1000Hz)
80, 100, 120, 140, 160, 180, 200,
220, 240, 260, 80, 300Hz
(Select OFF for 1000Hz)
Analog Input Range -C1V: 0 to 10V; -C2A: 4 to 20mA
Analog Input Impedance -C1V: 12K

; -C2A: 250

Operating Temperature Range -20º to 70º C (operating); -40º to 85º C (storage)
Enclosure Glass filled Nylon
Dimensions Inch: 2.4 L x 1.2 W x 0.75 H; Mm: 60 L x 30 W x 19 H
