021-MVP-Cxx-(D1) Rev A

MVP-C-(D1) User Manual

10

Copyright © High Country Tek, Inc.

– 2013

MVP-Cxx-(D1)

Valve Controller

Parameter List

The following table outlines the MVP-F parameters as well as the limits and units of measure for each parameter.

Parameter

Limits

Units

MVP-Cxx-xxx-(D1)

Version #

Mode

See Mode Description

Mode #

Minimum input

0 to 10.0

4 to 20.0

V

mA

Maximum input

0 to 10.0

4 to 20.0

V

mA

Minimum output

0 to 600

*

mA

Maximum output

0 to 600

*

mA

Ramp up

0.0 to 120.0

Seconds

Ramp down

0.0 to 120.0

Seconds

Dither frequency (MVP-C)

30 to 300,

(select OFF for 1000Hz)

Hz.

Dither frequency (MVP-Cxx-xxx-D1)

80 to 300,

(select OFF for 1000Hz)

Hz

Output current

mA

Supply voltage

Volts

Fault status

Fault

*

0 to 1.2A for

–12A version, 0 to 2.5A for –25A version for MVP-C

*

0 to 2.5A for

–25A version for MVP-Cxx-xxx-D1
