Hydraulic Fan System Controller : HFS - 2
Software Setup Guide – ( OEM & Factory Password level ):
2
1
3
5
6
9
10
4
7
8
The major differences between the OEM level and the Factory level passwords is the ability at the Factory
At OEM d F t d l l th f ll b 1 D d li t f il bl t f di l 5
The major differences between the OEM level and the Factory level passwords is the ability at the Factory
level to ‘ RESET’ data values in the ‘Permanent Log’ that have been stored during the controllers operation.
Both levels allow the user full access to all controller parameters so password confidentiality
should be of a high priority.
At OEM and Factory password levels, the full menu bar
options are displayed and available. 1
Alarm and Status text window.
Error messages are in RED text.
The window stays as above while there are no errors or
alarms reported by the system and/or controller.
2
Drop down list of available parameters for display. 5
Digital representation of the parameter being displayed in 6
4
Selects Slow, Medium or Fast graph time base setting. 7
Clicking this button starts the data logging process.
ALL of the parameters available in the item drop down
menu as well as other profile settings are logged for a
period of 256 samples . After the logging period, a popup
window asks for file name and storage location.
This file is saved with a *.csv extension which allows direct
import, reading and graphing in Microsoft Excel.
3
5
Selects Graphic window scaling between FULL scale or
AUTO. Auto gives better resolution for lower values.
8
General parameter set-up area for controller. See following
section in this manual for further details.
9
23
Window where ‘Real-time’ graphing of selected parameter
in is displayed. 4
5
Thermistor Enable and set-up controls. See following
section in this manual for further information. 10
