4.2: Standard Objects
4.2.1: Identity Object (Class ID = 1)
Attribute ID Access Rule Name Data Type Value
1 Get Vendor UNIT 0x009C
2 Get Product Type UINT 0x0000
3 Get Product Cod UINT 0x07C2
4 Get Revision STRUCT 01.00
5 Get Status WORD 0x0000
6 Get Serial # UDINT 0x00000001
7 Get Product Name STRUCT 15, “1986DN Resolver”
4.2.2: Message Router Object (Class ID = 2)
There is no externally visible interface to the Message Router Object.
4.2.3: DeviceNet Object (Class ID = 3)
There is a single instance of the DeviceNet Object for the DeviceNet Resolver. No class attributes are
supported.
Attribute ID Access Rule Name Data Type Value
1 Get/Set MACID USINT 0x63
2 Get/Set Baud Rate USINT 125K
3 Get/Set BOI BOOL 0x00 Hold in Reset
4 Get/Set Bus-off Counter USINT 0x00
5 Get Allocation Information STRUCT Allocate Service
4.2.4: Connection Object (Class ID = 5)
There are three instances of the connection object. Instance #1 is assigned to the explicit messaging
connection. Instance #2 is assigned to the Polled I/O connection. Instance #3 is assigned to the bit-strobe
I/O connection.
