AMETEK 1990 DN DeviceNet Resolver Interface Module User Manual
Page 2
2
1080 N. Crooks Road • Clawson, MI 48017 • 800.635.0289 • 248.435.0700 • Fax 248.435.8120 • www.AMETEKAPT.com
Contents
Chapter 1: Overview ............................... 3
Chapter 2: DeviceNet Information ......... 4
2.1 LED Operation ...............................................................4
2.2 I/O Messaging ................................................................4
2.3 Data Format ...................................................................4
Chapter 3: Getting Started ..................... 5
3.1 Establishing DeviceNet Communications ..................5
3.2 Configure the Node Address and Baud Rate .............5
3.3 Parameter Configuration ..............................................5
3.3.1 Scale Factor........... .............................................5
3.3.2 Counting Direction ...............................................5
3.3.3 Position Offset .....................................................6
3.3.4 Setpoints .............................................................6
Chapter 4: DeviceNet Object Model ....... 7
4.1 Object Model ..................................................................7
4.1.1 Objects Present in the DeviceNet Resolver ........7
4.1.2 Objects That Effect Behavior ...............................7
4.1.3 Object Interfaces .................................................7
4.1.4 Identificatoin of I/O Assembly Instances ..............7
4.1.5 Format of I/O Assembly Data Attributes ..............8
4.2 Standard Objects ..........................................................9
4.2.1 Identity Object (Class ID = 1) ..............................9
4.2.2 Message Router Object (Class ID = 2) ................9
4.2.3 DeviceNet Object (Class ID = 3) .........................9
4.2.4 Connection Object (Class ID = 5) ........................9
4.2.5 Parameter Object (Class ID = 15) .......................11
4.3 Application Specific Objects ........................................17
4.3.1 Position Object (Class ID = 100) .........................17
4.3.2 Setpoint Object (Class ID = 101) .........................17
4.3.3 RPM Object (Class ID = 102) ..............................17
4.4 Configuration Notes ......................................................18
Appendix .................................................. 19
Product and EMC Specifications, Approvals ....................19
This manual will instruct the user in programming
the GEMCO DeviceNet Resolver based products. It
is intended to cover the DeviceNet Resolver related
items only. Other, product specific, information may
be available in separate literature shipped with the
product.
Ametek has checked the accuracy of this manual
at the time it was printed. Any comments you
may have for the improvement of this manual are
welcomed.
Ametek reserves the right to revise and redistribute
the entire contents or selected pages of this manual.
All rights to the contents of this manual are reserved
by Ametek.
