Appendix
Specifications
Resolver
Resolution
12 bit resolution (4096 counts)
RPM 1024 max.
DeviceNet
Conformance
This product has been tested by
ODVA’s authorized Independent Test
Lab and found to comply with ODVA
Conformance Test Software Version
A-12.
Power Requirements
Inrush
92mA @ 11Vdc typical
67mA @ 24Vdc typical
350mA @ 11Vdc for 20 ms
450mA @ 25Vdc for 10 ms
Device Type “Generic”
Communications Group 2 slave only
Messages supported Polled, Bit Strobed, Explicit
Baud Rates
125K, 250K, 500K
Data
Update Rate
Position Rate
RPM
915µs
29.29 ms
Scale Factor 2 to 4096
Position Range 0 to 1 less than scale factor
Setpoints Separate ON and OFF points for each
setpoint
Quantity 8
Range 0 to 1 less than scale factor
Approvals CE
Environmental
Temperature
Operating
Storage
-20°C to +70°C
-40°C to +85°C
EMC Specifications
Specifications and Related Documents
The DeviceNet Resolver was tested to and complied with
the limits of the following specifications:
EN50081-1:1992
EN55011/A:1999
EMC, Generic emission standard,
Light Industrial Limits and methods of
measurement of radio characteristics
of industrial, scientific and medical
(ISM) Radio Frequency equipment,
Class B, Group 1.
EN50082-2:1995
EN61000-4-2:1995
EN61000-4-3:1998
+ Amendment 1
EN61000-4-4:1995
ENV50144:1993
Generic immunity standard, Industrial
ESD Immunity,
Performance Criteria B.
Radiated RF Immunity,
Performance Criteria A.
Electrical Fast Transient Immunity,
Performance Criteria B.
Conducted RF Immunity,
Performance Criteria A.
EN61010-1:1993 Safety Requirements for Electrical
Equipment for Measurement, Control
and Laboratory Use.
NOTE: To meet EMC requirements, add Ferrite (Fair-Rite
Corporation P/N: 0444167281) to resolver cable located
adjacent to DeviceNet connector.
