Bit Strobe I/O Message Connection Object (Instance #3)
Attribute ID Access Rule Name Data Type Value
1 Get State USINT 0x03
2 Get instance_type USINT 0x01
3 Get Xport Class trigger USINT 0x82
4 Get Produced connection ID UINT 0x3BF for MAC ID 63
5 Get consumed connection ID UINT 0x408 for MAC ID 1
6 Get initial comm characteristics USINT 0x02
7 Get produced connection size UINT 0x0005
8 Get consumed connection size UINT 0x0008
9 Get/Set expected packet rate UINT Application Dependent
10 N/A N/A N/A Not Used
11 N/A N/A N/A Not Used
12 Get Watchdog timeout action USINT 0x00
13 Get Produced path length UINT 0x0006
14 Get Produced path Array of USINT 0x20 0x04 0x24 0x01 0x30 0x03
15 Get consumed path length UINT 0x0000
16 Get consumed path Array of USINT
4.2.5: Parameter Object (Class ID = 15)
The parameter object supports the class attributes and 20 instances.
Class Attributes
Attribute ID Access Rule Name Data Type Value
2 Get Max Instance UINT 0x0014
8 Get Parameter Class Descriptor WORD 0x0009
9 Get Configuration Assembly Instance UINT 0x0002
