SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A
OPERATOR’S MANUAL SUPPLEMENT 5 of 15
You can create up to eight motion zones for every
Preset scene. An example of a Preset scene with
one motion zone is shown in Figure 6
Figure 6.
IMPORTANT NOTE : Motion Detection will not
function under certain Camera Functions settings.
Before programming, verify the following:
• IR Mode must not be set to ON.
• WDR must not be set to ON.
Follow the steps below to change the IR Mode and
WDR settings:
1. Access
the Dome Configuration Menu
(Figure 7) by pressing Iris Open, Focus Far
and Zoom Out on your controller.
Figure 7.
2. Use the joystick to highlight Camera
Functions and press Focus Far to select. The
Camera Functions screen appears (Figure 8).
Figure 8.
3. Use the joystick to highlight the IR MODE field
and press the Zoom In/Out button to change
settings. Options are OFF, ON, Auto Low, Auto
Mid, Auto High.
4. Use the joystick to highlight the WDR field and
press the Zoom In/Out button to change
settings. Options are On, OFF.
5. Use the joystick to highlight EXIT and press
Focus Far to select.
6. When the Dome Configuration Menu
appears, use the joystick to highlight EXIT
AND SAVE CHANGES and press Focus Far.
Steps to Programming Motion
Detection
Follow the steps below to program motion
detection.
1. Access the Dome Configuration Menu
(Figure 9) by pressing Iris Open, Focus Far
and Zoom Out on your controller.
Figure 9.
2. Use the joystick to highlight Alarms / Areas /
Home / Presets / PZ and Press Focus Far to
select. The Alarms / Areas / Home / Presets /
PZ screen appears (Figure 10).
MOTION DETECTION SETUP
PRESET 1
ZONE 1
ESC/FOCUS = save & exit
One
motion
zone
DOME CONFIGURATION MENU
PAN / TILT / ZOOM / SYNC OPTS
CAMERA FUNCTIONS
ALARMS / AREAS / PRESETS / PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
CAMERA FUNCTIONS
Auto White Bal
ON
IR MODE
Auto Low
WDR OFF
AGC/Shutter Max Gain Limit
Open Shutter
28 dB 1/4 s
RESET TO FACTORY SETTINGS
EXIT
DOME CONFIGURATION MENU
PAN / TILT / ZOOM / SYNC OPTS
CAMERA FUNCTIONS
ALARMS / AREAS / PRESETS / PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
