SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A
OPERATOR’S MANUAL SUPPLEMENT 4 of 15
Figure 2.
2. Use the joystick to highlight Alarms / Areas /
Home / Presets / PZ and Press Focus Far to
select. The Alarms / Areas / Home / Presets /
PZ screen appears (Figure 3).
Figure 3.
3. Use the joystick to highlight Presets and press
Focus Far to select. The Select Preset To
Program screen appears (Figure 4).
Figure 4.
4. Use the joystick to highlight the PRESET
NUMBER field and press the Zoom In/Out
button until your desired Preset number
appears.
5. Use the joystick to highlight Camera
Functions and press the Focus Far button.
The Camera Functions screen appears
(Figure 5).
Figure 5.
6. Make your desired changes. For details on the
Camera Functions screen, consult Chapter 3
of the Day/Night Camera Dome Configuration
Utility Operator’s Manual, 8200-0184-04.
7. Use the joystick to highlight EXIT and press the
Focus Far button to select. The Select Preset
to Program screen appears.
8. Program (or reprogram) the Preset by selecting
FOCUS FAR to program preset (see Note on
page 3).
Programming Motion
Detection
Applicable Day/Night SpeedDome cameras are
capable of providing motion detection based on
Preset camera views. Motion detection can be
programmed for any of the 96 Presets defined in
the dome. The motion detection feature is
programmed from the Select Preset to Program
screen.
Understanding Motion Zones
Motion Detection is programmed by positioning
motion zones (represented by rectangular blocks)
within a Preset scene. When motion occurs within
any of the motion zones, the dome will respond by
triggering the action you programmed for it—either
an output, a Preset, a Pattern, or by taking no
action.
DOME CONFIGURATION MENU
PAN / TILT / ZOOM / SYNC OPTS
CAMERA FUNCTIONS
ALARMS / AREAS / PRESETS / PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
ALARMS/AREAS/HOME/PRESETS/PZ
SET ALARM ACTIONS
SET ALARM STATES
SET HOME POSITION
SET NORTH POSITION
AREA BOUNDARIES
PRIVACY ZONES
PRESETS
SCAN LIMITS
EXIT
SELECT PRESET TO PROGRAM
PRESET PRESET NAME
NUMBER
1-96
PRESET 1-96
MOTION DETECTION SETUP
SEQUENCE SETUP MENU
CAMERA FUNCTIONS
FOCUS FAR to program preset
EXIT
CAMERA FUNCTIONS
Auto White Bal
ON
IR MODE
Auto Low
WDR OFF
AGC/Shutter Max Gain Limit
Open Shutter
28 dB 1/4 s
RESET TO FACTORY SETTINGS
EXIT
CAMERA FUNCTIONS
Auto White Bal
ON
IR MODE
Auto Low
WDR OFF
AGC/Shutter Max Gain Limit
Open Shutter
28 dB 1/4 s
RESET TO FACTORY SETTINGS
EXIT
