SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A
OPERATOR’S MANUAL SUPPLEMENT 2 of 15
DirectSet Menu
The DirectSet Menu provides easy access to
commonly used SpeedDome Ultra VIIE features
when used with compatible controllers. This allows
you to change or activate features without starting
the dome configuration menu. See Figure 1 for
examples of the Day/Night camera DirectSet
menu.
Figure 1: Day/Night Camera Dome DirectSet
Menu (3 screens)
To access a feature on the menu, enter the
number and press the DirectSet button (varies by
controller). Table 1 provides a description of the
available options.
Table 1: DirectSet Menu Options
Command Description
0+DirectSet
Toggle DirectSet Menu: Toggles
between displaying and hiding
the DirectSet menu.
1+DirectSet Dome Config Menu: Displays the
SpeedDome Ultra configuration
menu.
2+DirectSet Auto Iris/Auto Focus: Resumes
Auto Focus/Auto Iris mode.
3+DirectSet Flip: Rotates the SpeedDome
180° from its current pointing
direction. This is the same as
pressing the Flip button on
compatible controllers.
4+DirectSet Peel Pattern: Runs the default
Apple Peel Pattern. This is the
same as pressing the Peel button
on compatible controllers.
10+DirectSet Night Mode: Sets the dome IR
mode setting to ON. The dome
switches to full-time black-and-
white (B/W) mode.
11+DirectSet Day Mode: Sets the dome IR
mode setting to OFF. The dome
switches to full-time color mode.
12+DirectSet Auto Day/Night Mode: Resumes
the most recently selected
automatic IR mode setting.
• Auto High: B/W mode activates
~30 lux.
• Auto Mid: B/W mode activates
~3 lux.
• Auto Low: B/W mode activates
~ 0.5 lux
13+DirectSet WDR On: Enables Wide Dynamic
Range (WDR). Use this setting
when both bright and low light
areas need to be viewed
simultaneously.
14+DirectSet WDR Off: Disables Wide
Dynamic Range (WDR). Use this
setting when the light level is
constant or when changes in
lighting conditions are gradual.
15+DirectSet Smooth Scan: Initiates a smooth
360° clockwise rotation around
the dome axis using the current
tilt, zoom and focus settings.
0 TOGGLE DIRECT SET MENU
1 DOME CONFIG MENU
2 AUTO IRIS/AUTO FOCUS
3 FLIP
4 PEEL
PATTERN
10 NIGHT MODE
11 DAY MODE
12 AUTO DAY/NIGHT MODE
13 WDR
ON
14 WDR OFF
FOCUS NEAR = next page
15 SMOOTH SCAN
16 STEPPED
SCAN
17 RANDOM SCAN
20 DOME INFORMATION
51 SEQUENCE 1
52 SEQUENCE 2
53 SEQUENCE 3
54 SEQUENCE 4
55 SEQUENCE 5
56 SEQUENCE 6
FOCUS NEAR = next page
57 SEQUENCE 7
58 SEQUENCE 8
59 SEQUENCE 9
60 SEQUENCE 10
61 SEQUENCE 11
62 SEQUENCE 12
63 SEQUENCE 13
64 SEQUENCE 14
65 SEQUENCE 15
66 SEQUENCE 16
FOCUS NEAR = previous page
