SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A
OPERATOR’S MANUAL SUPPLEMENT 13 of 15
Specifications-Indoor Dome
Operational
Pan/Tilt:
Manual Pan Speed .........................0.2°-100° per second
(scaled to zoom position)
Manual Tilt Speed......................... 0.25°-100° per second
(scaled to zoom position)
Preset Pan/Tilt Speed............ 220° per second maximum
Pan Travel ................................. 360° continuous rotation
Tilt Travel................................................................ >100°
Pan/Tilt Accuracy..................................................... ±0.5°
23x Day/Night Camera Zoom Functions:
Optical Zoom ............................................................. 23X
Digital Zoom .............................................................. 10X
Zoom Pause ......................................... 23X selectable or
35X
default
Total Zoom .............................................................. 230X
Maximum Zoom Stop....... 46X, 69X, 92X (default), 115X,
138X, 161X, 184X, 207X, 230X
Zoom/Focus Accuracy ........................................... ±0.5%
Auto Synchronization:
Line Locked ........................ Remote V-phase adjustment
Internal.......................................... Built-in sync generator
Address Range....................................................... 1-255
Number of Presets:
VM16 / ADTT16........................... 96 with SensorNet 485
VM32 / AD32 ............................... 96 with SensorNet 485
AD2150..............................................64 with Manchester
16 with RS-422 (using AD2083-02A)
VM96 .................... Virtual with RS-422 or SensorNet 485
VM168 / AD168 ................................64 with Manchester,
RS-422 or SensorNet
16 with RS-422 (using AD2083-02A)
AD2050..............................................64 with Manchester
16 with RS-422 (using AD2083-02A)
Direct View™ Access Time ...........<1 second to position.
Full zoom in <4 seconds.
Focus on VM16, VM32 and
VideoManager systems is <1 second.
Focus on VM96 and RV2715 systems
is <7 seconds
Programmable Patterns
Number Patterns...........................................................16
Storage
Program Storage ................ 256 Kbytes of Flash memory
Data Storage .................................. 128 Kbytes of SRAM
Configuration Menu
Languages ................English, French, German, Spanish,
Italian, and Portuguese
Electrical
Input Voltage.....................................18-30Vac, 50/60 Hz
UL Class 2 LPS
Design Tolerance ..............................16-36Vac, 50/60 Hz
Power Consumption......................................... 16W max.
Current ........................................................... 0.85A max.
Allowable Drop Out ............................................... 100ms
Power On In-Rush Current........................................1.5A
Surge Protection:
Video Output ............................... Low capacitance Zener
suppressor 6.5V, 1500W
Power Line ......................... TVS rated at 60V, 1.5 joules,
250A 8/20µs impulse
RS-422.......................................... TVS rated at 9.8V/1A,
20V/25A,
500W,
8/20µs impulse
Manchester/
SensorNet 485 .................... Gas discharge tube rated at:
8/20µs impulse discharge current
of 10kA, ten 8/20µs impulse
discharge current of 5kA
Isolation transformer coupled 2000Vrms
PTC fuse protects transformer.
TVS rated at 9.8V/1A, 20V/25A,
500W, 8/20µs impulse
Alarm Input.................................... TVS rated at 9.8V/1A,
20V/25A, 500W, 8/20µs impulse
Alarms Inputs/Control Outputs:
When no I/O board is used:
Inputs ........................................ 1 dry contact/3.5mA sink
Outputs ......................................... 1 open collector driver
@ 12Vdc, 40mA
When I/O board is used:
Inputs ...................................... 4 dry contacts/3.5mA sink
Outputs ....................................... 4 open collector drivers
@ 12Vdc, 40mA
Environmental
Operating Temperature........ –10° to 50°C (14° to 122°F)
Relative Humidity .....................0 to 95% non-condensing
Storage Temperature ................................ –20°C to 65°C
(–4°F to 149°F)
