SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A
OPERATOR’S MANUAL SUPPLEMENT 14 of 15
Mechanical
Height ...........................................................20.8cm (8in)
Eyeball Diameter ..........................................12cm (4.7in)
Weight:
Housing and Eyeball ...............................1.36kg (3 lbs)
Base (standard).................................. 0.09kg (0.20 lbs)
Base (with I/O board) ......................... 0.16kg (0.35 lbs)
Lens and Bubble Densities
Eyeball Lens ..................................................................f0
Bubbles:
RUCLR (Clear)...........................................................f0
RUSLV (Silver)........................................................f2.0
RUSMK (Smoke).....................................................f1.0
RUGLD (Gold).........................................................f2.0
Specifications
–
23X Day/Night Camera
Type............................. Interline transfer 1/4in CCD array
Scanning Area ................................. 3.2 (H) x 2.4 (V) mm
Scanning System.......................................... 2:1 interlace
Video Out............................ 1.0 Vp-p/75 ohms composite
Signal-to-Noise ..........................................50 dB (typical)
Horizontal Resolution.......................... 470 lines at center
Minimum Illumination ........ 0.5 lux (AGC On, 20 IRE)
0.03 lux with 1/4 s open shutter
0.01 lux in IR mode
0.009 lux in IR mode with 1/4 s open shutter
White Balance ........................... Through-the-Lens (TTL)
Automatic
Tracing
White balance (ATW)
NTSC:
Effective Pixels ........................... 724 (H) x 494 (V) pixels
Scanning........................... 525 lines, 60 fields, 30 frames
Horizontal ....................................................... 15.734kHz
Vertical.................................................................. 59.9Hz
PAL:
Effective Pixels ........................... 724 (H) x 582 (V) pixels
Scanning........................... 625 lines, 50 fields, 25 frames
Horizontal ....................................................... 15.625kHz
Vertical..................................................................... 50Hz
Lens Design
Type ................................................................ Aspherical
Focal Length ............................................. 3.6 to 82.8mm
Aperture .................................................f1.6 (wide angle)
f3.7
(telephoto)
Viewing Angle (equivalent to 8-80 mm on 1/2" CCD
array, or 11-110 mm on 2/3" CCD array):
3.6mm ................................................54.0°(H) x 40.5°(V)
82.8mm ..................................................2.5°(H) x 1.9°(V)
Field-of-View Formulas:
3.2mm* x distance from camera (m)
Focal length (mm)
= Horizontal view (m)
2.4mm** x distance from camera (m)
Focal length (mm)
= Vertical view (m)
* Horizontal scanning area of pickup device (mm) in camera.
** Vertical scanning area of pickup device (mm) in camera.
Example: Wide angle view with lens at 6mm and viewed
object at 10m.
3.2mm x 10m
6mm
= 5.33m Horizontal view (m)
2.4mm x 10m
6mm
= 4.0m Vertical view (m)
