SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY
8200-0184-12, REV. A
OPERATOR’S MANUAL SUPPLEMENT
11 of 15
VM16E/ADTT16E (Black Touch
Tracker)
Supported Protocol
SensorNet
RS-422
1
Maximum Presets
96 – SensorNet
4 – RS-422
Maximum Patterns
2
16
DirectSet Menu
Yes
3
Address Range
1-16 or 1-64
3
Notes:
(1) Requires RCSN422 code converter.
(2) Patterns are limited by time and the number of
available dome commands.
(3) Requires firmware version 0701-2833-0103
(EEPROM) / 0701-2834-0201 (Flash PROM) or
newer.
VM32/AD32
Supported Protocol
SensorNet
RS-422
1
Maximum Presets
96 – SensorNet
4 – RS-422
Maximum Patterns
2
16
DirectSet Menu
Not supported
Address Range
1-32
Notes:
(1) Requires RCSN422 code converter.
(2) Patterns are limited by time and the number of
available dome commands.
VM96
1
Supported Protocol
SensorNet
RS-422
Maximum Presets
9,999
2
Maximum Patterns
3
16
DirectSet Menu
Not supported
Address Range
1-32
Notes:
(1) Requires software version 5.2 or newer.
(2) Preset information is stored at the host, not the
dome; therefore, divide 9,999 by the number of
domes to determine number of available Presets per
dome.
(3) Patterns are limited by time and the number of
available dome commands.
AD2150/AD2350
Supported Protocol
RS-422
1
Maximum Presets
16
2
Maximum Patterns
3
16
DirectSet Menu
Not supported
Address Range
1-32
Notes:
(1) Requires the AD2083-02 series code converter.
(2) Preset information is stored at the converter, not the
dome.
(3) Patterns are limited by time and the number of
available dome commands.
AD1650
Supported Protocol
RS-422
1
Maximum Presets
16
2
Maximum Patterns
3
16
DirectSet Menu
Not supported
Address Range
1-128
4
Notes:
(1) Requires the AD2083-02 series code converter.
(2) Preset information is stored at the converter, not the
dome.
(3) Patterns are limited by time and the number of
available dome commands.
(4) Requires additional equipment to achieve these
numbers. A dome address within each group of 64
or 99 cameras is reserved as a global broadcast
address.
AD168
Supported Protocol
SensorNet
1
RS-422
1
or 2
Maximum Presets
16
1, 2
, 64
1, 3
Maximum Patterns
4
16
DirectSet Menu
Not supported
Address Range
SensorNet: 1-180
RS-422: 1-99
1, 5
or 1-180
2, 5
Notes:
(1) Requires the appropriate code control module.
(2) Requires the AD2083-02 series code converter.
(3) Presets information is stored at the converter or
control module, not the dome.
(4) Patterns are limited by time and the number of
available dome commands.
(5) Requires additional equipment to achieve these
numbers. A dome address within each group of 64
or 99 cameras is reserved as a global broadcast
address.
