Operating and Installation Instructions
CONA
®
-control
To delete a slave address:
- Change to configuring mode:
There must not be a bus connection to a higher-level system. Disconnect the bus
connector (if connected).
Press the "Mode" button for at least five seconds. The "prj mode" LED lights up and the
connected slaves are shown in the digital display for 0.5 seconds.
- When the slave address you want to change appears, press "SET". The display stops
scrolling. If you release the "SET" button briefly, the next slave is displayed. If you keep
the "SET" button pressed for at least five seconds, the selected address is deleted.
- If a slave with the address 00 is displayed as the slave addresses are scrolled, the AS-i
master / gateway is still in configuring mode.
To set the address of slave 0:
- In configuring mode, press the "SET" button briefly. The next free slave address is
displayed.
- By pressing the "SET" button briefly, you can select the required free slave address.
- The address blinks if you press the "SET" button for longer than five seconds.
- By pressing the "SET" button briefly, you store the new slave address.
Store the AS-i configuration:
- To confirm the current configuration:
Press the "Mode" button again for at least five seconds. The "fault" indications should then
disappear and the incorrectly configured slaves should no longer be shown.
6.2.3 Process data for higher-level bus systems
If the measuring amplifiers are used with the central status indication, they are preset in the
factory to AS-i addresses 1a to 30a. The corresponding indication cards are preset to
addresses 1b to 30b.
Indication card 1b is assigned to measuring amplifier 1a, etc.
Input data according to AS-i V2.1 mode:
Byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
0
Flags Slave 1A Measuring Amplifier
Configu-
ration Active
Periphery
Fault
AS-i Power
Fail
Config
Error
Steam
Leakage
Blockage - -
1
Slave 2A Measuring Amplifier Slave 3A Measuring Amplifier
Steam
Leakage
Blockage - -
Steam
Leakage
Blockage - -
2
Slave 4A Measuring Amplifier Slave 5A Measuring Amplifier
Steam
Leakage
Blockage - -
Steam
Leakage
Blockage - -
3
Slave 6A Measuring Amplifier Slave 7A Measuring Amplifier
Steam
Leakage
Blockage - -
Steam
Leakage
Blockage - -
4
Slave 8A Measuring Amplifier Slave 9A Measuring Amplifier
Steam
Leakage
Blockage - -
Steam
Leakage
Blockage - -
5
Slave 10A Measuring Amplifier Slave 11A Measuring Amplifier
Steam
Leakage
Blockage - -
Steam
Leakage
Blockage - -
