7
LEDS
STS – STATUS LED
The Status LED is a dual color LED that provides information regarding the
state of the module. This includes indication of the various stages of the start-up
routine (power-up), as well as any errors that may occur.
Startup Routine
FIRMWARE UPGRADE
The module’s firmware is stored in flash memory to prevent software/hardware
conflicts, and so that software features may be added in the future.
During a download, Crimson compares its own library of firmware files with
those stored in the Master module. If they do not match, Crimson will download
the necessary files. The Master then checks to make sure that the I/O modules
contain the same firmware. If they contain a different revision, the Master will
automatically copy those files into the module's flash memory. During this
process, the module LEDs will flash rapidly, starting with the top row, and
progressing through the remaining rows until the process is complete.
Error States
OP1, OP2, OP3, OP4* – OUTPUT STATUS LED
The OP1, OP2, OP3, and OP4* LEDs are factory configured to indicate the
status of the outputs. The LEDs turn on when the output is active.
These LEDs may be remapped to various other module properties.
*CSPID2 only
ALM OR AL1 & AL2 – ALARM LED
The Alarm LEDs are factory configured to indicate the presence of an alarm.
Whenever one of the seven alarms is active, the LED turns on.
These LEDs may be remapped to various other module properties.
CONFIGURATION
Programming is done via Crimson ® software, a Windows ® compatible
configuration interface. Please see the Crimson manual for more information.
Rapidly Flashing Red
Module is currently running the boot loader and/or
being flash upgraded by Crimson. This occurs for
four seconds during a power up.
Steady Red Module switching to configuration.
Green Module performing normally.
Module is controlling properly, but has lost
communication with the Master.
Green/Pulsing Red
Module not controlling, and not communicating. Solid Red
ORDERING INFORMATION
TYPE MODEL NO. DESCRIPTION PART NUMBER
Master Module CSMSTR
Modular Controller Master, Multi Comms ports and Ethernet CSMSTRV2
Modular Controller Master with multiple protocol converter, Ethernet
and expansion slot
CSMSTRLE
Modular Controller Master with multiple protocol converter, data
logger, web server with Virtual HMI up to QVGA (320 x 240) size and
expansion slot.
CSMSTRSX
Modular Controller Master with multiple protocol converter, data
logger, web server with Virtual HMI up to VGA (640 x 480) size and
expansion slot with increased SDRAM
CSMSTRGT
PID Control Modules
CSPID1 1
Single Loop Module, Relay Outputs CSPID1R0
Single Loop Module, Relay Outputs, Analog Output CSPID1RA
Single Loop Module, Relay Outputs, Heater Current Input CSPID1RM
Single Loop Module, Solid State Outputs CSPID1S0
Single Loop Module, Solid State Outputs, Analog Output CSPID1SA
Single Loop Module, Solid State Outputs, Heater Current Input CSPID1SM
Single Loop Module, Triac Outputs, Analog Output CSPID1TA
CSPID2
Dual Loop Module, Relay Outputs CSPID2R0
Dual Loop Module, Relay Outputs, Heater Current Input CSPID2RM
Dual Loop Module, Solid State Outputs CSPID2S0
Dual Loop Module, Solid State Outputs, Heater Current Input CSPID2SM
Dual Loop Module, Triac Outputs CSPID2T0
Dual Loop Module, Triac Outputs, Heater Current Input CSPID2TM
Communications Cables
(10 feet)
CBL
Programming Cable for CS, G3, & Paradigm Series CBLPROG0
Communications Cables 1 CBLxxxxx
Software
Crimson ® Programming Software 2 SFCRM
Crimson ® Programming Software, Manual, and Download Cable SFCRK
Accessories
Rail Stops (Qty 2) RSRSTP00
Replacement Base CSBASE00
Replacement Termination Plug CSTERM00
CT
50 Amp Current Transformer (For Heater Current Models)
UL Recognized component, Instrument Transformers, Inc.
Part #2SFT500-0.1
CT005001
Note: Certain modules are not suitable for use in Hazardous locations. Check each module’s specifications prior to installation.
1 Visit www.redlion.net for a complete list of PID modules, data acquisition modules, communications drivers and cables.
2 Free at www.redlion.net
