HEATER CURRENT MONITOR OPTION
The optional Heater Current Monitor input is useful for early warning of
heater degradation, or heater circuit failure. The input connects to a current
transformer with an output of 100 mA AC to ensure that proper heater current is
present when the control output is on, and that little or no current is present when
the output is off. This option provides immediate warning of a circuit short or
open, instead of waiting for a high or low temperature shutdown alarm.
SAFETY SUMMARY
All safety related regulations, local codes and instructions that appear in the
manual or on equipment must be observed to ensure personal safety and to
prevent damage to either the instrument or equipment connected to it. If
equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
Do not use the controller to directly command motors, valves, or other
actuators not equipped with safeguards. To do so can be potentially harmful to
persons or equipment in the event of a fault to the controller. An independent
and redundant temperature limit indicator with alarm outputs is strongly
recommended.
SPECIFICATIONS
1. POWER: Derived from system backplane. (CSPID1 draws 150 mA max. load
on power input of MASTER, CSPID2 draws 125 mA max). Modules may be
hot-swapped (Replaced while powered up).
2. LEDs*:
STS - Status LED shows module condition
OP1, OP2, OP3, OP4 - Indicate status of outputs 1, 2, 3, and 4
ALM, or AL1 and AL2 - Alarm LEDs are lit during any internal alarm
condition
* Default configuration.
3. MEMORY: Non-volatile memory retains all programmable parameters.
MASTER also stores the parameters in order to reprogram modules that are
replaced.
4. INPUT:
GENERAL:
Sample Time: 67 msec (15 Hz)
Common Mode Rejection: >110 dB, 50/60 Hz
Normal Mode Rejection: >40 dB, 50/60 Hz
Temperature Coefficient: 0.01%/°C
Step Response Time: 200 msec typ., 250 msec max
THERMOCOUPLE INPUTS:
Types: T, E, J, K, R, S, B, N, C
Input Impedance: 20 M Ω
Lead Resistance Effect: 0.25 µV/Ω
Cold Junction Compensation: Less than ±1°C typical (±1.5°C max) over 0
to 50 °C ambient temperature
Resolution: 0.1°
RTD INPUTS:
Type: 2 or 3 wire
Excitation: 150 µA
Lead Resistance: 15 Ω Max
Resolution: 1 or 0.1°
PROCESS INPUT:
INPUT
RANGE
ACCURACY
(18 TO 28 °C)
IMPEDANCE
MAX CONTINUOUS
OVERLOAD
RESOLUTION
10 V 0.1% span 1 M Ohm 50 V 16 bit
20 mA 0.1% span 10 Ohm 100 mA 16 bit
5. TEMPERATURE INDICATION ACCURACY: ± (0.3% of span, +1°C).
Includes NIST conformity, cold junction effect, A/D conversion errors,
temperature coefficient and linearization conformity at 23 °C after 20 minute
warm up.
6. ISOLATION LEVEL: 500 Vrms @ 50/60 Hz for 1 minute between the
following:
OP1
OP2
OP3
OP4
Linear Output (CSPID1 only)
Signal Inputs and HCM
CS Master Power Supply Input
7. COMMUNICATIONS: Provided by the CS Master
8. A/D CONVERTER: 16 bit resolution
9. DISCRETE OUTPUTS:
CSPID1: Outputs 1 and 2 available as Solid State NFET, Form A relay or
Triac. Output 3 is a Form C relay.
CSPID2: Outputs 1 through 4 available as Form A relay, Solid State NFET,
or Triac.
Solid State Output:
Type: Switched DC, N Channel open drain MOSFET
Current Rating: 1 A max
VDS ON: 0.3 V @ 1 A
VDS MAX: 30 VDC
Offstate Leakage Current: 0.5 mA max
Form A Relay Output:
Type: N.O.
Current Rating: 3 Amps @ 125 VAC
1/10 HP @ 125 VAC
Life Expectancy: 200,000 cycles at maximum load rating. (Decreasing
load, increasing cycle time, and use of surge suppression such as RC
snubbers increases life expectancy.)
Form C Relay Output:
Type: SPDT
Current Rating: 5 Amps @ 125 VAC or 28 VDC (resistive load)
1/8 HP @ 125 VAC
Life Expectancy: 100,000 cycles at maximum load rating. (Decreasing
load, increasing cycle time, and use of surge suppression such as RC
snubbers increases life expectancy.)
Triac: (CSPID1TA only)
Type: Optically isolated, zero-crossing detection
Rating: 120 VAC, Min: 20 VAC
Max Load Current: 1.0 A across Operating Temperature Range
Min Load Current: 5 mA
Offstate Leakage Current: 1 mA Max
Operating Frequency: 20 to 400 Hz
Protection: Internal Transient Suppression, Fused
Triac: (CSPID2T0 and CSPID2TM only)
Type: Optically isolated, zero-crossing detection
Rating: 120 VAC, Min: 20 VAC
Max Load Current: 0.5A @ 25°C, 0.4A @ 50°C
Min Load Current: 5 mA
Offstate Leakage Current: 1 mA Max
Operating Frequency: 20 to 500 Hz
Protection: Internal Transient Suppression, Fused
10. CONTROL MODES:
Control: On/Off, P, PI, or PID
Output: Time proportioning or linear (CSPID1 only)
Cycle Time: Programmable from 0.0 to 60.0 sec
Auto-Tune: When selected, sets proportional band, integral time, derivative
time values, and output dampening time
Probe Break Action: Programmable response
Sensor Fail Response: Upscale
TYPE
MEASUREMENT
RANGE
WIRE COLOR
ANSI BS 1843
T
-200 to +400°C
-328 to +752°F
(+) Blue
(-) Red
(+) White
(-) Blue
E
-200 to +730°C
-328 to +1346°F
(+) Violet
(-) Red
(+) Brown
(-) Blue
J
-200 to +760°C
-328 to +1400°F
(+) White
(-) Red
(+) Yellow
(-) Blue
K
-200 to +1350°C
-328 to +2462°F
(+) Yellow
(-) Red
(+) Brown
(-) Blue
R
0 to +1768°C
+32 to +3214°F
No Standard
(+) White
(-) Blue
S
0 to +1768°C
+32 to +3214°F
No Standard
(+) White
(-) Blue
B
+149 to +1820°C
+300 to +3308°F
No Standard No Standard
N
-200 to +1300°C
-328 to +2372°F
(+) Orange
(-) Red
(+) Orange
(-) Blue
C
W5/W6
0 to +2315°C
+32 to +4199°F
No Standard No Standard
mV -5 mV to 56 mV N/A N/A
TYPE INPUT TYPE RANGE
385 100 Ω platinum, Alpha = .00385
-200 to +600°C
-328 to +1100°F
392 100 Ω platinum, Alpha = .003919
-200 to +600°C
-328 to +1100°F
672 120 Ω nickel, Alpha = .00672
-80 to +215°C
-112 to +419°F
