540 min
-1
1000 min
-1
Pn
Mn
Pn
Mn
kw
CV-HP PS N•m
kw
CV-HP PS
N•m
1
12
16
210
18
25
172
2
15
21
270
23
31
220
3
22
30
390
35
47
330
43
26
35
460
40
55
380
4
26
35
460
40
55
380
5
35
47
620
54
74
520
6
47
64
830
74
100
710
7
55
75
970
87
118
830
8
70
95
1240
110
150
1050
9
88
120
1560
140
190
1340
10
106
145
1890
170
230
1630
NOMINAL POWER Pn and NOMINAL TORQUE Mn
All rotating parts must be shielded.
The tractor master shield, the driveline guard, and the implement shield all
work together for your safety.
Do not operate without all driveline, tractor and implement shields in place.
Damaged or missing parts must be repaired with original spare parts or
replaced before using the driveline. The driveline must be securely attached at
both ends. Guards must turn freely on the driveline.
Disengage the PTO, turn off the tractor engine, remove the key and ensure
that all rotating parts have stopped before approaching the implement or
performing maintenance work.
Keep clear of the work area and rotating parts. Do not wear loose clothing,
jewelry, or hair that could become entangled with the driveline. Contact with
rotating parts can cause serious injury or death.
Do not stand on the driveline. Do not step over, or go under, the driveline.
Telescoping tubes must always overlap by at least 1/2 of their length in normal
operation and at least 1/3 of their length in all working conditions. During
maneuvers, when the driveline is not rotating, the telescoping tubes must have a
suitable overlap to maintain the tubes aligned and allow then to slide freely.
Use STATIONARY MACHINERY (pumps, elevators, generators, dryers, etc.)
only when hitched to the tractor.
Brake the tractor, placing blocks under the wheels if necessary. The tractor must
be hitched to the implement and positioned so that the angles of the joints are
minimal and equal.
CARDAN JOINTS
When operating, ensure that joint angles are small and equal: a1 = a2.
During turns or other short duration maneuvers, the maximum recommended joint
angle is 45°. Disengage the PTO if the angles are too large or not identical.
