8
HighPoint RAID Management (HRM)

Hot key (ctrl-h) boot-up RAID manager via BIOS

Web browser-base RAID management software (Web GUI)

Command Line Interface (CLI) – FreeBSD/Linux
Operating System Support

Windows XP, 2003, Windows Vista, Windows 2008, Windows 7 (32 and 64-bit versions)

Linux (Fedora Core, Red Hat Enterprise / CentOS, SuSE, Debian Ubuntu)

FreeBSD

Mac OS X (RR2744 only)
PHYSICAL SPECIFICATIONS (RR2740)
Size: 220.0mm X 68.0mm
EMI: FCC Part 15 Class B and CE
PHYSICAL SPECIFICATIONS (RR2744)
Size: 107.0 mm×140 mm×1.6mm
EMI: FCC Part 15 Class B and CE
Thermal and Atmospheric Characteristics:
Work Temperature Range: +5 C ~+ 55 C
Relative Humidity Range: 5% ~ 60% non-condensing
Storage Temperature: -20 ~ +80 C
MTBF: 920,585 Hours
Electrical Characteristics:
PCI-E
3.3V 12V
Power 10W max 20W max
2 - Kit Contents

RocketRAID Host Adapter

Quick Install Guide

HighPoint RAID Management and software CD

Low profile bracket
