Installation and Owner’s Manual | TSAL B2B Series
5.0 GENERAL MAINTENANCE
5.1 How to Care for your Shelter Ad Light System
Solar Panel Cleaning
1. Once every three months the solar panels should be cleaned to insure optimum performance.
2. With a damp cloth thoroughly wipe down the solar panel removing any dirt and grime that may have
accumulated.
3. Dry the solar panel with a soft clean cloth and repeat if necessary.
Caution! During the day solar panels can become extremely hot.
Fuse Replacement
4. Periodically, the fuse used to protect the system circuitry may have to be replaced.
5. To replace the fuse turn the system disconnect to the “off” position.
6. Remove the fuse cover, remove the existing fuse, insert the new fuse, and replace the fuse cover.
7. Turn the system to the “on” position.
8. Make sure that the replacement fuse matches the specifications of the original fuse. One spare has
been provided with your system.
LED Fixture Replacement (LEDs last 50,000+ hrs.)
9. Turn the system disconnect to the “off” position.
10. Remove the fixture and replace with a new one.
11. Turn the system disconnect to the “on” position.
12. Push the white “test” button to make sure the system is working properly.
Battery Replacement (batteries are designed to last 5 years)
13. Turn the system disconnect to the “off” position.
14. Remove the battery harness from the old batteries and place on the new batteries (all three must be
replaced at once).
15. Turn the system disconnect to the “on” position.
16. Push the white “test” button to make sure the system is working properly.
