Air King 2EJR6G - Manual (Page 2)

Rev. E 2/08
2
2082048A Rev. E 2/08
7
2082048A
1. Mark screw locations on
inside edges of window trim
using enclosed template as
shown in illustration.
2. Drive 4 screws "A" into trim.
DO NOT TIGHTEN FLUSH.
Leave
1/8" (3.2 mm) space between
screw heads and window trim.
1/8” (3.2mm)
T
E
M
P
L A
T
E A
Figure 3
METHOD B: (Inside of Trim)
Tools Required: Hardware Provided:
Screwdrivers Four - #8 x 3/4" slotted head screws
Installation
The large number of window styles and types makes it impossible
to describe one universal installation procedure. The methods
outlined below are recommended as being well-suited for most
common styles of double-hung windows. Whichever method you
choose should allow the window to be closed easily for security
and protection of home furnishings against the weather. Refer to
illustrations while following Methods A or B below.
3. With side panel in posi-
tion, mark screw loca-
tions at top of slot "C"
and drive in the 4 wood
screws "A" (provided)
until tight.
4. Tighten 4 screws "B" in
fan housing to complete
installation.
Figure 2
2. Rest fan on window sill with flange on side panels over trim. Push in
side panels tight against outer edge of trim.
Figure 1
Slot
C
B
B
1. Loosen screws "B"
and extend side pan-
els to clear the outer
edge of trim on each
side of window.
METHOD A: (Outside of Trim)
Tools Required: Hardware Provided:
Screwdrivers Four - #8 x 3/4" slotted head screws
A
A
B
4. Mount fan in window
by engaging slots "C"
with screws "A" on
inside edge of trim.
Lower fan on screws
"A" until it rests on
window sill or sash
moulding.
Slot
C
A Figure 5
5. Tighten screw "B" on
housing to secure
fan in position.
A
B
B
3. Loosen 4 screws "B"
and entend panels
on each side of
housing until the fan
fits snugly between
right and left window
trim.
Slot
C
B
B
Figure 4
Figure 6
Operation
This Air King® window fan is powered by a durable electrically-reversible
3 speed split capacitor motor. (Hi, Medium, and Low speed settings are
available for both intake and exhaust mode.) The motor control switch
is conveniently located on the motor cover. Adjust knob to direction and
speed desired.
MAINTENANCE
WARNING: ALWAYS UNPLUG THE CORD BEFORE SERVICING.
CLEANING: Use a soft cloth and a mild soap solution such as liquid
dish washing detergent.
NEVER IMMERSE ELECTRICAL PARTS IN WATER.
CAUTION: Do not use gasoline, benzine, thinner, harsh cleaners, etc.
which will damage the fan.
Dry all parts with a soft cloth completely before reconnecting
to power supply.
STORAGE: When not in use, keep unit in a clean dry place.
MOTOR IS PERMANENTLY LUBRICATED.
MODEL 2EJR6G/9155G
WHAT THIS WARRANTY COVERS: This product is warranted against defects in workmanship and/or materials.
HOW LONG THIS WARRANTY LASTS: This warranty extends only to the original purchaser of the product and lasts for one (1) year from the
date of original purchase or until the original purchaser of the product sells or transfers the product, whichever first occurs.
WHAT AIR KING WILL DO: During the warranty period, Air King will, at its sole option, repair or replace any part or parts that prove to be
defective or replace the whole product with the same or comparable model.
WHAT THIS WARRANTY DOES NOT COVER: This warranty does not apply if the product was damaged or failed because of accident, improper
handling or operation, shipping damage, abuse, misuse, unauthorized repairs made or attempted. This warranty does not cover shipping
costs for the return of products to Air King for repair or replacement. Air King will pay return shipping charges from Air King following
warranty repairs or replacement
ANY AND ALL WARRANTIES, EXPRESSED OR IMPLIED (INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY OF
MERCHANTABILITY), LAST ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE OR UNTIL THE ORIGINAL PURCHASER
OF THE PRODUCT SELLS OR TRANSFERS THE PRODUCT, WHICHEVER FIRST OCCURS AND IN NO EVENT SHALL AIR
KING'S LIABILITY UNDER ANY EXPRESS OR IMPLIED WARRANTY INCLUDE (I) INCIDENTAL OR CONSEQUENTIAL
DAMAGES FROM ANY CAUSE WHATSOEVER, OR (II) REPLACMENT OR REPAIR OF ANY HOUSE FUSES, CIRCUIT
BREAKERS OR RECEPTACLES. NOTWITHSTANDING ANYTHING TO THE CONTRARY, IN NO EVENT SHALL AIR KING’S
LIABILITY UNDER ANY EXPRESS OR IMPLIED WARRANTY EXCEED THE PURCHASE PRICE OF THE PRODUCT AND ANY
SUCH LIABILITY SHALL TERMINATE UPON THE EXPIRATION OF THE WARRANTY PERIOD.
Some states and provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or
consequential damages, so these exclusions or limitations may not apply to you. This warranty gives you specific legal rights. You may also
have other rights which vary from state to state and province to province.
Proof of purchase is required before a warranty claim will be accepted.
LIMITED WARRANTY
QUÉ CUBRE ESTA GARANTÍAS: Este producto está garantizado contra defectos de mano de obra y/o materiales.
CUÁNTO DURA ESTA GARANTÍA: Esta garantía se extiende únicamente al comprador original del producto y dura un (1) año a partir de
la fecha original de compra o hasta que el comprador original del producto venda o transfiera el producto, cualesquiera de ambas que
ocurriera en primer lugar.
QUÉ HARÁ AIR KING: Durante el período de garantía, Air King, a opción propia, reparará o reemplazará cualquier parte o partes que demuestren
ser defectuosas o reemplazará el producto completo por el mismo modelo u otro comparable.
QUÉ NO CUBRE ESTA GARANTÍA: Esta garantía no tiene validez si el producto fue dañado o falló debido a un accidente, manipulación u
operación inadecuadas, daño en el envío, abuso, mal uso, reparaciones no autorizadas hechas o el intento de hacerlas. Esta garantía no
cubre los costos de envío para la devolución de productos a Air King para su reparación o reemplazo. Air King abonará los cargos de envío
de devolución a Air King con posterioridad a las reparaciones o el reemplazo bajo garantía
CUALESQUIERA Y TODAS LAS GARANTÍAS, EXPLÍCITAS O IMPLÍCITAS (INCLUYENDO, SIN LIMITACIÓN, CUALESQUIERA
GARANTÍA IMPLÍCITA DE COMERCIABILIDAD), DURAN UN AÑO A PARTIR DE LA FECHA ORIGINAL DE COMPRA O HASTA
QUE EL COMPRADOR ORIGINAL DEL PRODUCTO VENDA O TRANSFIERA EL PRODUCTO, CUALESQUIERA DE AMBAS
QUE OCURRIERA EN PRIMER LUGAR Y EN NINGÚN CASO LA RESPONSABILIDAD DE AIR KING BAJO CUALQUIER
GARANTÍA EXPLÍCITA O IMPLÍCITA INCLUIRÁ (I) DAÑOS INCIDENTALES O POR CONSECUENCIA POR CUALQUIER
CAUSA QUE FUERE, O (II) REEMPLAZO O REPARACIÓN DE CUALESQUIERA FUSIBLES HOGAREÑOS, CORTA-CIRCUITOS
O TOMACORRIENTES. INDEPENDIENTEMENTE DE CUALQUIER DECLARACIÓN CONTRARIA, EN NINGÚN CASO LA
RESPONSABILIDAD DE AIR KING BAJO CUALQUIER GARANTÍA EXPLÍCITA O IMPLÍCITA PODRÁ EXCEDER EL PRECIO DE
COMPRA DEL PRODUCTO Y DICHA RESPONSABILIDAD TERMINARÁ AL VENCIMIENTO DEL PERÍODO DE GARANTÍA.
Algunos estados y provincias no permiten limitaciones sobre la duración de una garantía implícita, o sobre la exclusión o limitación de los
daños incidentales o por consecuencia, por lo tanto dichas exclusiones o limitaciones podrían no aplicarse en su caso. Esta garantía le
otorga a usted derechos legales específicos. Usted también podría tener otros derechos que varían de estado en estado y de provincia en
provincia.
Se requiere prueba de compra antes que se acepte un reclamo bajo garantía.
GARANTÍA LIMITADA
MODEL/MODELO 2EJR6G/9155G
